In Houston, at Luke Steel, we provide higher quality ABS DH36 Shipbuilding Steel Sheets and Plates that enjoy good weldability, durability, and strength in adverse marine environments. ABS fully certified, DH36 is ideal for high stress service in shipbuilding and offshore engineering. We offer flexible delivery and fabrication solutions to shipyards, oil rigs, and infrastructure constructions. Luke Steel aims to supply reliable, high-quality material that meets international marine standards for safety and quality.
ABS DH36 has ~0.18–0.22% Carbon, with Manganese and Silicon, and microalloying elements for better toughness. It has a yield strength ≥355 MPa and tensile strength of 490–620 MPa. DH36 has good resistance to impact at -20°C, which is why it is used in cold sea climates. It is usually supplied in normalized or controlled-rolled condition to provide maximum mechanical performance and structural integrity.
STANDARD: ASTM A131, ASME SA131
PLATES QUALITY: DH36 (Dead Soft Quality)
THICKNESS: 3/16″ – 4″, 4-60mm
WIDTH: 48″ – 120″, 2000 / 2500 / 3000mm
LENGTH: 96″ – 480″, 6000 / 8000 / 10000 / 12000 mm
Grade DH36 | C | Si | Mn | P | S | V | Al | Cr | Cu | Mo | Nb | Ni | Ti |
0.180 | 0.1-0.5 | 0.90-1.6 | 0.035 | 0.035 | 0.05-0.10 | 0.015 | 0.200 | 0.350 | 0.080 | 0.02-0.05 | 0.400 | 0.020 |
Grade | Re | Rm | Elongation | |
---|---|---|---|---|
A50mm | A200mm | |||
MPa | MPa | % | % | |
DH 36 | 355 | 490/620 | 22 | 19 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Luke Steel is one of the most prominent manufacturers and suppliers of superior quality ABS DH36 Shipbuilding Steel Sheet and Plates in Houstan, USA. As experts in steel solutions, we supply a complete spectrum of products like Carbon Steel, Alloy Steel, Mild Steel, and Galvanized Steel. Our product range comprises Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets, and Plates. Known for our reliable delivery and first-rate customer service, we are committed to supplying high-quality steel materials that guarantee durability and excellent performance in numerous industrial applications.
theoretical weight | Thickness (mm) | Thickness (mm) | theoretical weight | ||
---|---|---|---|---|---|
Kg/m2 | Kg/ft2 | Kg/m2 | Kg/ ft2 | ||
47.10 | 4.376 Kg/ft2 | 6 | 25 | 196.25 | 18.962 Kg/ ft2 |
54.95 | 5.105 Kg/ft2 | 7 | 26 | 204.10 | 20.420 Kg/ ft2 |
86.35 | 8.751 Kg/ft2 | 11 | 32 | 251.20 | 25.525 Kg/ ft2 |
172.70 | 16.044 Kg/ft2 | 22 | 50 | 392.50 | 36.464 Kg/ ft2 |
62.80 | 5.834 Kg/ft2 | 8 | 28 | 219.80 | 21.879 Kg/ ft2 |
157.00 | 14.586 Kg/ft2 | 20 | 48 mm | 376.80 | 35.006 Kg/ ft2 |
78.50 | 7.293 Kg/ft2 | 10 | 30 mm | 235.50 | 23.337 Kg/ ft2 |
94.20 | 10.21 Kg/ft2 | 12 | 34 mm | 266.90 | 26.254 Kg/ ft2 |
125.60 | 11.669 Kg/ft2 | 16 | 40 mm | 314.00 | 29.172 Kg/ ft2 |
141.30 | 13.127 Kg/ft2 | 18 | 45 mm | 353.25 | 32.818 Kg/ ft2 |
109.90 | 10.939 Kg/ft2 | 14 | 35 mm | 274.75 | 27.713 Kg/ ft2 |
188.40 | 18.232 Kg/ft2 | 24 |
Max. width | Thickness |
---|---|
DH36 | From to up to |
1370 | 1.70 to 1.80 |
1280 | 1.60 to 1.70 |
1440 | 1.80 to 1.90 |
1520 | 1.90 to 2.00 |
1170 | 1.49 to 1.60 |
2070 | 12.70 to 20.00 |
1590 | 2.00 to 2.20 |
1730 | 2.20 to 2.40 |
1880 | 2.60 to 2.80 |
1960 | 2.80 to 3.12 |
1800 | 2.40 to 2.60 |
2070 | 3.12 to 12.70 |
DH36 is employed extensively for the construction of medium and large commercial vessels, tankers, and offshore platforms. It is best suited for bottom hull plates and other regions that experience high pressure and impact. The excellent mechanical properties of the steel also enable applications in dry docks, floating production facilities, and marine cranes. In applications outside the marine industry, DH36 finds application in port facilities and industrial fabrication demanding higher performance in corrosive environments.
