Alloy Steel Hex Bars are made from a blend of elements like carbon, manganese, chromium, molybdenum, nickel, and vanadium, which boost their strength, hardness, and resistance to wear. These bars usually showcase impressive tensile strength, ranging from 600 to 850 MPa, along with excellent yield strength between 350 and 650 MPa. Thanks to their remarkable hardness and fatigue resistance, they also provide good machinability and thermal stability. The exact composition varies based on the alloy grade, making these hex bars perfect for tough structural, mechanical, and industrial applications.
Alloy Steel Hex Bars are popular in a variety of industries because of their outstanding strength and durability. In construction, they’re used to create structural frameworks and supports. In the automotive and aerospace fields, these bars play a crucial role in producing fasteners, shafts, gears, and engine components. They’re also found in the oil and gas, power plants, and heavy machinery sectors due to their ability to withstand stress and wear. Their hexagonal shape enhances grip and torque transfer, making them ideal for precision components and threaded parts in mechanical assemblies.
| Specifications | ASTM A182, ASME SA182 |
|---|---|
| Dimensions | EN, DIN, JIS, ASTM, BS, ASME, AISI |
| Range | 5mm to 500mm Dia in 100mm to 6000mm Length |
| Diameter | 10 mm To 200 mm |
| Thickenss | 0.5mm to 500mm Diameter |
| High Speed Steel (HSS), HCHCR & OHNS in Grade | M2, M3, M35, M42, T-1, T-4, T-15, T-42, D2, D3, H11, H13, OHNS-01 & EN52 |
| Finish | Black, Bright Polished, Rough Turned, NO.4 Finish, Matt Finish, BA Finish |
| Length | 1000 mm Long To 6000 mm Long |
| Form | Round, Square, Hex (A/F), Rectangle, Billet, Ingot, Forging Etc. |
| Element | C | Cr | Mn | Mo | P | S | Si | Ni |
| F5 | 0.15 Max | 4.0-6.0 | 0.30-0.60 | 0.44-0.65 | 0.035 Max | 0.030 Max | 0.50 Max | 0.50 Max |
| F1 | 0.15 Max | 3.0-5.0 | 0.30-0.60 | 0.40-0.50 | 0.035 Max | 0.030 Max | 0.50 Max | 0.50 Max |
| F22 | 0.05-0.15 | 2.00-2.50 | 0.30-0.60 | 0.90-1.10 | 0.035 Max | 0.040 Max | 0.50 Max | – |
| F91 | 0.08-0.12 | 8.0-9.5 | 0.30-0.60 | 0.85-1.05 | 0.020 Max | 0.010 Max | 0.20-0.50 | 0.40 Max |
| F9 | 0.15 Max | 8.0-10.0 | 0.30-0.60 | 0.90- 1.10 | 0.030 Max | 0.030 Max | 0.50- 1.00 | – |
| F11 | 0.10-0.20 | 1.00-1.50 | 0.40-0.65 | 0.44-0.65 | 0.025 Max | 0.040 Max | 0.50-0.80 | – |
| Grade | Tensile Strength (ksi) min | Elongation (% in 50mm) min | Yield Strength 0.2% Proof (ksi) min |
| F9 | 415 | 30 | 205 |
| F5 | 275 | 485 | 20 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Luke Steel is a top manufacturer and supplier of high-quality Alloy Steel Hex Bar products in Houstan, USA. Specializing in steel solutions, we provide a wide range of products, including Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel. Our offerings include Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates. Known for our reliable delivery and superior customer service, we are committed to offering top-tier steel materials that ensure durability and performance across a wide range of industrial applications. We strive to meet the highest standards, making us a trusted partner for all your steel needs.
Luke Steel is a reliable manufacturer and supplier of top-notch Alloy Steel Hex Bars based in Houston, USA. With a focus on precision engineering and durability, we offer hex bars that meet international standards and fulfill the demanding needs of various industries. Our products are recognized for their dimensional accuracy, corrosion resistance, and exceptional mechanical properties. Supported by state-of-the-art manufacturing facilities and a skilled team, Luke Steel provides dependable alloy solutions to clients in construction, automotive, and energy sectors, ensuring performance excellence and long-lasting value in every bar.
Luke Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Houstan, USA.
