Luke Steel is a top supplier of Alloy Steel 4140 Fasteners in Houston. These components are high-strength and versatile, making them ideal for demanding industrial applications. 4140 fasteners are built for strength, wear resistance, and high toughness. This makes them suitable for heavy-duty mechanical and structural applications. With Luke Steel’s commitment to quality and timely delivery, engineers and manufacturers can rely on these fasteners for both critical and high-load bearing assemblies in industries like automotive, construction, and machinery manufacturing.
Alloy Steel 4140 Fasteners are made up of 0.40% carbon, 1% chromium, and 0.2% molybdenum. These elements contribute to their high strength, wear resistance, and toughness. The steel generally shows a tensile strength between 850 and 1000 MPa, a yield strength of 655 MPa, and an elongation of 15%. Heat treatment methods, such as quenching and tempering, are often used to improve these mechanical properties even more. The material offers strong resistance to fatigue and impact, ensuring durability under tough operational conditions.
| Standard | ASTM A193, ASTM A194 / ASME SA193, SA194 GR, IS, BS |
| Specification | IS, BS, ASTM |
| Size | M 02 to M 160 |
| Length | UPTO 5 METERS |
| Grade | B 6, B 7/ B 7M, B 16, 2, 2HM, 2H, GR 6, B 7, B 7M |
| Type | Bolts, nuts, Washers, Anchor Fasteners, Stud Bolts, Eye Bolt, Stud, Threaded Rod, Cotter Pin, Socket Screw, Fine Fasteners & Spares, Foundation Fasteners, etc. |
| Element | AISI 4140 |
| Fe | 96.785 – 97.77 |
| Cr | 0.80 – 1.10 |
| Mn | 0.75 – 1.0 |
| C | 0.380 – 0.430 |
| Si | 0.15 – 0.30 |
| Mo | 0.15 – 0.25 |
| S | 0.040 |
| P | 0.035 |
| Grade AISI 4140 | Metric | Imperial |
| Tensile strength | 655 MPa | 95000 psi |
| Yield strength | 415 MPa | 60200 psi |
| Bulk modulus (Typical for steel) | 140 GPa | 20300 ksi |
| Shear modulus (typical for steel) | 80 GPa | 11600 ksi |
| Elastic modulus | 190-210 GPa | 27557-30458 ksi |
| Poisson’s ratio | 0.27-0.30 | 0.27-0.30 |
| Elongation at break (in 50 mm) | 25.70% | 25.70% |
| Hardness, Brinell | 197 | 197 |
| Hardness, Knoop (converted from Brinell hardness) | 219 | 219 |
| Hardness, Rockwell B (converted from Brinell hardness) | 92 | 92 |
| Hardness, Rockwell C (Converted from Brinell hardness, value below normal HRC range, for comparison purposes only.) | 13 | 13 |
| Hardness, Vickers (converted from Brinell hardness) | 207 | 207 |
| Machinability (Annealed and cold drawn. Based on 100% machinability for AISI 1212 steel.) | 65 | 65 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| Grade AISI 4140 | Metric | Imperial |
| Thermal expansion co-efficient (@ 0-100°C/32-212°F) | 12.2 µm/m°C | 6.78 µin/in°F |
| Thermal conductivity (100°C) | 42.6 W/mK | 296 BTU in/hr.ft².°F |
