Luke Steel is a trustworthy producer and distributor of premium Alloy Steel AISI 52100 Bars in Houstan, USA. Renowned for our pursuit of excellence, we deliver accurate–tolerancing engineered steel bars that satisfy global standards for strength, dependability, and performance. With extensive industry experience, we cater to major sectors such as automotive, aerospace, bearings, and machinery production. Our AISI 52100 bars are premium in wear resistance, hardness, and dimensional stability and are excellent for stress and precision applications. Supported by effective logistics, prompt delivery, and competitive pricing, Luke Steel is a reliable partner throughout the USA and international markets.
AISI 52100 Alloy Steel Bars consist of high carbon (~1.0%) and high chromium (~1.5%), which provide them with hardness, strength, and abrasion resistance. Other constituents such as silicon, manganese, and trace sulfur enhance machinability and toughness. Following heat treatment, the bars have a tensile strength of 700 to 1000 MPa, high fatigue strength, and dimensional stability. They are also characterized by better polishability and surface finish when precision machining is used. Wear resistance and hardenability of the steel render it a leading candidate for critical applications needing durability and close tolerances.
| Dimensions | EN, DIN, JIS, ASTM, BS, ASME, AISI |
| Size | 5 mm To 500 mm |
| Diameter | 0.1 mm to 100 mm |
| Length | 100 mm To 6000 mm Long & Above |
| Finish | Black, Bright Polished, Rough Turned, NO.4 Finish, Matt Finish, BA Finish |
| Tolerance | H8, H9, H10, H11, H12, H13K9, K10, K11, K12 or as per clients’ requirements |
| Form | Round, Square, Hex (A/F),Flate, Rectangle, Billet, Ingot, Forging Supplier |
| Stainless Steel | ASTM A-479, A-182, 304, 304L,304H,304S, 316, 316L,316 Ti, 316H, 309, 310, 310S, 317L, 321, 347, 409, 410, 420, 430, 440, 446, 904L. etc. |
| Duplex Steel | 2205, 31803, 32750, 32760, 2101, 2304. |
| Alloy Steel | A-182 – F5, F9, F11, F12, F21, F22 & F91 |
| Special Grade | Stainless Steel 17-4 PH, Alloy 800, Alloy 600. Hastelloy C276. |
| Carbon Steel | A 105, LF 2, Duplex Steel. |
| Element | Content (%) | ||
| SAE / AISI 52100 | Min | Max | |
| Carbon | C | 0.98 | 1.1 |
| Chromium | Cr | 1.3 | 1.6 |
| Manganese | Mn | 0.25 | 0.45 |
| Silicon | Si | 0.15 | 0.35 |
| Sulfur | S | – | 0.025 |
| Phosphorous | P | – | 0.025 |
| USA | Germany | China | Japan | France | England | Italy | ISO | Czechia | Austria | Sweden | Spain |
| AIAI/ASTM/SAE/UNS | DIN,WN-r | GB | JIS | AFNOR | BS | UNI | ISO | CSN | ONORM | SS | UNE |
| E52100/ G52986 | 100Cr6 (W3) / 1.3505 | GCr15 | SUJ2 | 100C6 | 535A99 | 100Cr6(B1) | SKF3 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| Sizes Chart in Milimeter | Sizes in Inch | Thickness Chart In MM | Thickness Chart In Inches |
|---|---|---|---|
| 22 | 7/8 | 17 & 18 | 2/3 – 5/7 |
| 25 | 1 | 5 to 20 | 3/16 – 4/5 |
| 30 | 1-3/16 | 5 to 20 | 3/16 – 4/5 |
| 32 | 1-1/4 | 6 to 20 | 1/4 – 4/5 |
| 35 | 1-3/8 | 5 to 20 | 3/16 – 3/16 |
| 40 | 1-4/7 | 5 to 25 | 3/16 – 1 |
| 45 | 1-7/9 | 5 to 25 | 3/16 – 1 |
| 47 | 1-6/7 | 17,25 & 32 | 2/3, 1 & 1-1/4 |
| 50 | 2 | 5 to 32 | 3/16 – 1-1/4 |
| 55 | 2-1/16 | 5 to 25 | 3/16 – 1 |
| 57 | 2-1/4 | 32 | 1-1/4 |
| 60 | 2-3/8 | 5 to 35 | 3/16 – 1-3/8 |
| 63 | 2-1/2 | 10 to 30 | 3/8 – 1-3/16 |
| 65 | 2-5/9 | 10 to 30 & 35 | 3/8 – 1-3/16, & 1-3/8 |
| 70 | 2-3/4 | 6 to 25 & 40 | 1/4 – 1, & 1-4/7 |
| 75 | 3 | 8 to 25 | 5/16 – 1 |
| 80 | 3-1/8 | 8 to 20 | 5/16 – 4/5 |
| 90 | 3-1/2 | 8 to 20 | 5/16- 4/5 |
| 100 | 4 | 8, 10, 12 | 5/16, 3/8, 1/2 |
AISI 52100 Alloy Steel Bars are broadly applied in applications where there is a need for high wear resistance and mechanical performance. They are an ideal material in the production of bearings, utilized in ball bearings, roller bearings, and bearing races, owing to their superior fatigue strength and surface hardness. In automobile applications, the bars are employed for gears, axles, and driveshafts. Aerospace and tooling markets depend on them for components that are high-stress, dies, and precision tools. The uniform microstructure of the steel, precise dimensional control, and retention of properties under load are desirable for precision components used in severe environments.
