Luke Steel, a top-notch manufacturer and supplier located in Houston, Houstan, proudly offers high-quality Alloy Steel AISI 8620 Bars. These bars are celebrated for their remarkable toughness, wear resistance, and case hardenability. Crafted with precision and a strict commitment to international standards, they’re perfect for components that need a strong core and a hard surface. Luke Steel provides AISI 8620 bars in a variety of sizes, finishes, and heat treatment options to cater to a wide range of industrial requirements. With a solid focus on quality control, timely delivery, and customer satisfaction, Luke Steel has become a reliable source for high-performance alloy steel bar solutions.
Alloy Steel AISI 8620 Bars are made up of carbon (0.18–0.23%), manganese (0.70–0.90%), chromium (0.40–0.60%), nickel (0.40–0.70%), and molybdenum (0.15–0.25%). This combination of elements strikes a perfect balance between toughness, strength, and wear resistance. Typically, these bars showcase a tensile strength ranging from 620 to 885 MPa and a yield strength between 415 and 655 MPa, depending on the heat treatment applied. AISI 8620 is known for its excellent case hardening properties, which allow the surface to harden while keeping the core ductile. This makes it an excellent choice for high-performance mechanical applications.
| AISI 8620 Steel Round Bar Plate Sheet Supply Range | |||||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Type | Specification | Surface | |||||||||||||||||
| Round Bar | Diameter: 16mm – 800mm; length: 2000mm-5000mm Other specifications can be customized. | Black Surface/Bright Surface/ Grinded/Peeled/Turned | |||||||||||||||||
| Sheet/Plate/Slab | Thickness: 16-800mm; width: 205mm-810mm; length: 2000mm-5000mm Other specifications can be customized. | Black Surface/Bright Surface/ Grinded/Peeled/Turned | |||||||||||||||||
| STAND | C(%) | Mn(%) | P(%) | S(%) | Si(%) | Cr(%) | Mo(%) | Ni(%) |
|---|---|---|---|---|---|---|---|---|
| ASTM A29/A29M-05 | 0.18-0.23 | 0.70-0.90 | ≤0.035 | ≤0.040 | 0.15-0.35 | 0.40-0.60 | 0.15-0.25 | 0.40-0.70 |
| EN 10084-2008 | 0.17-0.23 | 0.65-0.95 | ≤0.025 | ≤0.035 | 0.40 | 0.35-0.70 | 0.15-0.25 | 0.40-0.70 |
| JIS G4053-2008 | 0.17-0.23 | 0.60-0.90 | Max0.030 | Max0.030 | 0.15-0.35 | 0.40-0.60 | 0.15-0.25 | 0.40-0.70 |
| ISO 683/11:1987 | 0.17-0.23 | 0.65-0.95 | ≤0.035 | ≤0.035 | 0.15-0.40 | 0.30-0.65 | 0.15-0.25 | 0.40-0.70 |
| Properties | Metric | Imperial |
|---|---|---|
| Tensile strength | 530 MPa | 76900 psi |
| Yield strength | 385 MPa | 55800 psi |
| Elastic modulus | 190-210 GPa | 27557-30458 ksi |
| Bulk modulus (typical for steel) | 140 GPa | 20300 ksi |
| Shear modulus (typical for steel) | 80 GPa | 11600 ksi |
| Poisson’s ratio | 0.27-0.30 | 0.27-0.30 |
| Izod Impact | 115 J | 84.8 ft.lb |
| Hardness, Brinell | 149 | 149 |
| Hardness, Knoop (converted from Brinell hardness) | 169 | 169 |
| Hardness, Rockwell B (converted from Brinell hardness) | 80 | 80 |
| Hardness, Vickers (converted from Brinell hardness) | 155 | 155 |
| Machinability (hot rolled and cold drawn, based on 100 machinability for AISI 1212 steel) | 65 | 65 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| Country | USA | Germany/USA/France | JAPAN | ISO |
|---|---|---|---|---|
| Standard | ASTM A29/A29M-05 | EN 10084-2008 | JIS G4053-2008 | ISO 683/11:1987 |
| Grades | 8620 | 20NiCrMo2-2 (1.6523) | SNCM220 | 20NiCrMo2 |
You’ll find Alloy Steel AISI 8620 Bars widely used across the automotive, aerospace, and heavy machinery sectors for components like gears, crankshafts, camshafts, fasteners, and transmission parts. Their ability to undergo case hardening makes them perfect for parts that face high wear and fatigue, all while maintaining a tough and impact-resistant core. These bars are also utilized in construction equipment, agricultural machinery, and industrial tools. The blend of strength, ductility, and hardness guarantees long-lasting performance in dynamic and high-load environments, making AISI 8620 a go-to material for precision-engineered parts.
