High-performance alloy steel grade 22 coils designed to withstand the most demanding industrial conditions are available from Luke Steel, a reputable manufacturer and supplier with headquarters in Houston, USA. These coils are renowned for their remarkable resistance to oxidation, corrosion, and creep at high temperatures and are manufactured in accordance with ASTM specifications. Grade 22 coils are extensively utilised in vital applications in the petrochemical, oil and gas, and power generation industries due to their exceptional mechanical qualities and thermal stability. Luke Steel offers hot-rolled and cold-rolled coils with exceptional strength, dependability, and dimensional accuracy, backed by prompt service and stringent quality control guidelines.
Chromium (1.90–2.60%), molybdenum (0.87–1.13%), carbon (0.05–0.15%), manganese (0.30–0.60%), silicon (0.50% max), and trace amounts of phosphorus and sulphur make up Alloy Steel Grade 22 Coils. These coils have a minimum yield strength of 60,000 psi and an exceptional tensile strength between 75,000 and 95,000 psi. Grade 22, which is intended for high-temperature service, has outstanding corrosion protection, creep resistance, and thermal stability. In order to improve its mechanical integrity, the alloy is typically supplied in normalised and tempered condition. Boilers, pressure vessels, and other high-stress industrial settings that demand exceptional strength and longevity over extended service times are good candidates for it.
| Specifications | : | ASTM A387 / ASME SA387 |
| Thickness | : | 1mm-300mm |
| Width | : | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, 4050mm etc |
| Length | : | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, 12000mm, 15000mm etc |
| Surface | : | 2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, checkered, embossed, hair line, sand blast, Brush, etching, etc |
| Finish | : | Hot rolled plate (HR), Cold rolled sheet (CR) |
| Form | : | Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Strip etc. |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N |
| Alloy Steel Gr 22 | 0.05 – 0.15 | 0.30-0.60 | 0.50 max | 0.035 max | 0.035 max | 2.0 – 2.5 | 0.90 – 1.10 | – | – |
| Tensile (MPa) | Yield (MPa) | Elongation (50mm) | Elongation (200mm) | Reduction of Area |
| 415 – 585 | 205 min | 18% min | – | 40% min |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Jaxon Steel based in Houstan, USAis a trusted manufacturer and supplier for Alloy Steel Grade 22 Coil of great quality. In fact, we have earned our reputation for providing a variety of top-notch steel products-such as Structural Steel, Alloy Steel, Carbon Steel, Mild Steel, and Galvanized Steel-with emphasis on Structural Steel Sheets and Plates. Basic product lines include a complete range of Pipes, Tubes, Flanges, Forged Fittings, Bars, and other forms. Jaxon Steel is committed to its delivery and customer service, thus ensuring that they procure the best raw materials to guarantee high strength and durability with performance specifically for critical industrial applications. Contact us anytime for your Structural Steel Sheet and Plate needs!
For high-temperature, high-pressure applications in petrochemical plants, oil refineries, and power plants, alloy steel grade 22 coils are perfect. Because of their excellent resistance to oxidation and thermal fatigue, they are frequently used in the construction of headers, boiler tubes, pressure vessels, and heat exchangers. These coils can also be used to make valves, fittings, and flanges that are used in high-temperature settings. Grade 22 coils are utilised in both static and cyclic thermal conditions because of their superior weldability and structural integrity. They are a great option for critical infrastructure because of their long service life and resilience to stress.
