Luke Steel is a leading distributor of Alloy Steel T1 Tubing from Houston, Houstan, offering high-strength tubing solutions for boiler, heat exchanger, and pressure system applications. T1 tubing, or ASTM A209 Grade T1, is a carbon-molybdenum alloy steel tube with high temperature resistance and superior mechanical properties. Our T1 tubing, which is produced with stringent quality checks, finds extensive applications in thermal power stations and high-pressure systems. Luke Steel supplies tubes in a range of wall thicknesses and sizes to satisfy rigorous specifications in thermal fluid handling and high-stress applications.
Alloy Steel T1 Tubing consists of 0.10–0.20% carbon, 0.27–0.63% manganese, and 0.44–0.65% molybdenum. It possesses tensile strength of 415–585 MPa and yield strength of 220 MPa. T1 tubing excels under high-temperature conditions, withstanding structural integrity and low oxidation. Molybdenum addition improves creep and thermal fatigue life. The tubes are seamless and normally normalized or tempered to enhance grain structure, ductility, and weldability. Their strength and heat resistance make them perfect for long-term service in pressure conditions.
Alloy Steel T1 Seamless Tubes Specifications |
||
| Specifications | : | ASTM A/ASME SA213, A691 |
| Dimensions | : | ASTM, ASME and API |
| Tubes Size | : | 1 / 2” OD up to 5” OD, customs diameters also available |
| Outer Diameter | : | 6-2500mm; WT:1-200mm |
| Schedule | : | SCH20, SCH30, SCH40, STD, SCH80, XS, SCH60, SCH80, SCH120, SCH140, SCH160, XXS |
| Type | : | Seamless / EFW / Fabricated |
| Form | : | Round, Square, Rectangular, Hydraulic Etc |
| Length | : | Single Random, Double Random & Cut Length. |
| End | : | Plain End, Beveled End, Treaded |
|
Grade |
C≤ |
Mn |
P≤ |
S≤ |
Si≤ |
Mo |
|---|---|---|---|---|---|---|
|
T1 |
0.10~0.20 |
0.30~0.80 |
0.025 |
0.025 |
0.10~0.50 |
0.44~0.65 |
| Grade | Tensile Strength, MPa | Yield Strength, MPa | Elongation, % | Hardness, HB |
| T1 | 415 min | 205 min | 30 min | 163 max |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| Outside Diameter | OD Tolerance | WT Tolerance | Ovality Tolerance | Cut Length Tolerance |
| OD≤ 12, 7 mm | ± 0, 13 mm | ± 15 % | – | + 3, 18 mm, – 0 mm |
| 12, 7 mm < OD ≤ 38, 1 mm | ± 0, 13 mm | ± 10 % | max, 1, 65 mm | + 3, 18 mm, – 0 mm |
| 38, 1 mm < OD ≤ 88, 9 mm | ± 0, 25 mm | ± 10 % | max, 2, 41 mm | + 4, 76 mm, – 0 mm |
Jaxon Steel is a leading manufacturer and distributor of high-quality Alloy Steel T1 Tubing in Houstan, USA. We provide premium steel materials and a comprehensive range of products, including Alloy Steel, Carbon Steel, Mild Steel, and Galvanized Steel. Our extensive inventory features Tubes, Pipes, Flanges, Pipe Fittings, Forged Fittings, Sheets, and Plates. Dedicated to timely delivery and exceptional customer service, we use only the finest raw materials to ensure superior performance in industrial applications with stringent requirements. Contact us today for all your Alloy Steel T1 Tubing needs!
Alloy Steel T1 Tubing has far-reaching applications in superheaters, reheaters, water wall panels, and economizers of power plants and boiler systems. It finds perfect application in the generation of steam and thermal fluid transfer in high-pressure and high-temperature processes. Alloy Steel T1 Tubing finds applications in chemical refineries, petrochemical plants, and industrial heat recovery systems as well. T1 tubing resists cyclic thermal loads and corrosive environments, providing a long service life with minimal maintenance. Luke Steel provides tailor-made tubing sizes and lengths for maximum performance in thermal energy systems and fluid pressure management projects.
