Luke Steel is a renowned Alloy Steel T11 Tubing producer and exporter with its headquarters in Houston, USA. Known for producing precision-engineered and durable steel products, Luke Steel provides tubing solutions that meet global manufacturing and quality standards. With an unwavering dedication to the high demands of the power generation, petrochemical, and refinery industries, the company manufactures tubing that works efficiently under high-temperature and high-pressure conditions. Acclaimed throughout the Middle East, Houstan, and rest of the world, Luke Steel‘s Alloy Steel T11 Tubing is relied upon by virtue of its quality, strength, and engineering superiority.
Alloy Steel T11 Tubing contains chromium (1.00–1.50%) and molybdenum (0.44–0.65%), which give it mechanical strength, corrosion resistance, and thermal stability. Other constituents are carbon (≤0.15%), manganese, silicon, phosphorus, and sulfur, in proportions controlled to provide toughness and weldability. Mechanically, the tube has a minimum tensile strength of 415 MPa, yield strength of 205 MPa, and a minimum elongation of 30%, making it suitable for creep resistance and thermal fatigue in high-demand applications. Low carbon in the alloy also provides high ductility and weldability, enabling safer and more efficient operations.
| ASTM A213 T11 Specification & Standard | ASTM A213 T11, ASME SA213 T11 (with IBR Test Certificate) |
|---|---|
| SA 213 Gr T11 Specification | ASTM A213 & ASTM A209 (T1 , Ta, T1b) BS/3059/ 90/ Part II/ 620 & 622 DIN/ 17175/ 13CrMo44 DIN/ 17175/ 10CrMo910 DIN/ 17175/ 15Mo3 |
| T11 Steel Tube Sch. & Swg. | 10 Swg., 12 Swg., 14 Swg., 16 Swg., 18 Swg., 20 Swg., 3.6 mm Thk |
| ASME SA213 Grade T11 Tubing Size | 6.35 mm OD to 101.6 mm OD |
| A213 Grade T11 Pipe Thickness | 3-12mm |
| SA213 Grade T11 Material Origin | European, Japanese, Korean, US, Russian, Indian (Strictly No Chinese Material) |
| Craft | Cold rolled and Cold drawn |
| A213 Grade T11 Tube Type | Seamless / ERW / Welded / Fabricated |
| SA213 T11 Steel Tube available in Form of | Round, Square, Rectangular, Hydraulic Etc. |
| ASME SA213 Grade T11 Tube Tolerance | Cold drawn pipe: +/-0.1mm Cold rolled pipe: +/-0.05mm |
| SA 213 Gr T11 Tube Length | Standard Double & In Cut length also. |
| SA213 Grade T11 Tube End | Plain End, Beveled End, Treaded |
| A213 Grade T11 Additional Testing | NACE MR 0175, NACE TM0177, NACE TM0284, HIC TEST, SSC TEST, H2 SERVICE, IBR, etc. |
| Specialized in |
|
| SA 213 Gr T11 Tube Application & uses | Seamless Ferritic Alloy Steel Tube for High-Temperature Service |
| Grade | C≤ | Mn | P≤ | S≤ | Si≤ | Mo |
|---|---|---|---|---|---|---|
| SA213 T11 Composition | 0.05~0.15 | 0.30~0.60 | 0.025 | 0.025 | 0.50~1.0 | 0.44~0.65 |
| Grade | SA 213 T11 Tensile Strength, MPa | Yield Strength, MPa |
|---|---|---|
| T11 | 415 min | 205 min |
| SA 213 Gr T11 Density | Elongation, % | Hardness, HB |
| 7.85 g/cc | 30 min | 179 max |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| Outside Diameter | OD Tolerance | WT Tolerance | Ovality Tolerance | Cut Length Tolerance |
| OD≤ 12, 7 mm | ± 0, 13 mm | ± 15 % | – | + 3, 18 mm, – 0 mm |
| 12, 7 mm < OD ≤ 38, 1 mm | ± 0, 13 mm | ± 10 % | max, 1, 65 mm | + 3, 18 mm, – 0 mm |
| 38, 1 mm < OD ≤ 88, 9 mm | ± 0, 25 mm | ± 10 % | max, 2, 41 mm | + 4, 76 mm, – 0 mm |
Jaxon Steel is a leading manufacturer and distributor of high-quality Alloy Steel T11 Tubing in Houstan, USA. We provide premium steel materials and a comprehensive range of products, including Alloy Steel, Carbon Steel, Mild Steel, and Galvanized Steel. Our extensive inventory features Tubes, Pipes, Flanges, Pipe Fittings, Forged Fittings, Sheets, and Plates. Dedicated to timely delivery and exceptional customer service, we use only the finest raw materials to ensure superior performance in industrial applications with stringent requirements. Contact us today for all your Alloy Steel T11 Tubing needs!
Alloy Steel T11 Tubing has extensive use in power plants, refineries, and petrochemical plants, where equipment works at high-pressure and high-temperature environments. It finds perfect application in boiler tubes, reheaters, superheaters, and heat exchangers of steam-generating equipment. Its oxidation and corrosion resistance also make it a suitable option in chemical processing and thermal equipment. It is also employed in structural and mechanical applications with a need for strength, thermal stability, and extended service life. T11 Tubing provides superior safety of operation, lower maintenance, and better thermal efficiency, establishing it as a reliable unit in critical industrial operations.
