Luke Steel Manufacturer and Suppliers based in Houston, Houstan, is a premium supplier of Alloy Steel T9 Tubing designed for service under high temperature as well as high pressure. Conforming to the standards of ASTM A213, our T9 tubes are precision-made and perfectly suited for application in thermal power plants, petrochemical plants, and refineries. We at Luke Steel emphasize product reliability, delivery on time, and technical conformity, guaranteeing every length of T9 tubing satisfies the needs of stringent applications. Our technical experts work tirelessly to deliver premium–quality alloy tubing solutions supported by excellent quality control and industry knowledge.
Alloy Steel T9 Tubing consists of Chromium (8.0–10.0%), Molybdenum (0.90–1.10%), and Carbon (max 0.15%), and contains Manganese (0.30–0.60%) and Silicon (0.50–1.00%). The tube is heat-treated through normalizing and tempering, possessing excellent resistance to corrosion and heat. It provides a minimum tensile strength of 415 MPa and a minimum yield strength of 205 MPa with 30% elongation. These attributes enable T9 tubing to work efficiently in conditions with high temperature, thermal cycling, and internal pressure, particularly in reheaters and superheaters.
| ASTM A213 T9 Specification & Standard | ASTM A213 T9, ASME SA213 T9 (with IBR Test Certificate) |
|---|---|
| SA 213 Gr T9 Specification | ASTM A213 & ASTM A209 BS/3059/ 90/ Part II/ 620 & 622 DIN/ 17175/ 13CrMo44 DIN/ 17175/ 10CrMo910 DIN/ 17175/ 15Mo3 |
| T9 Steel Tube Sch. & Swg. | 10 Swg., 12 Swg., 14 Swg., 16 Swg., 18 Swg., 20 Swg., 3.6 mm Thk |
| A213 Grade T9 Tubing Size | 6.35 mm OD to 101.6 mm OD |
| SA213 Grade T9 Pipe Thickness | 3-12mm |
| ASTM A213 Grade T9 Tube available in Form of | Round, Square, Rectangular, Hydraulic Etc. |
| Craft | Cold rolled and Cold drawn |
| SA213 Grade T9 Tube Type | Seamless / ERW / Welded / Fabricated |
| A213 Grade T9 Tube Tolerance | Cold drawn pipe: +/-0.1mm Cold rolled pipe: +/-0.05mm |
| T9 Steel Grade Material Origin | European, Japanese, Korean, US, Russian, Indian (Strictly No Chinese Material) |
| SA213 T9 Steel Tube Length | Standard Double & In Cut length also. |
| T9 Steel Grade Tube End | Plain End, Beveled End, Treaded |
| SA213 Grade T9 Additional Testing | NACE MR 0175, NACE TM0177, NACE TM0284, HIC TEST, SSC TEST, H2 SERVICE, IBR, etc. |
| Specialized in |
|
| SA213 T9 Steel Tube Application & uses | Seamless Ferritic Alloy Steel Tube for High-Temperature Service |
| Grade | C≤ | Mn | P≤ | S≤ | Si≤ | Mo |
|---|---|---|---|---|---|---|
| SA213 T9 Composition |
0.15 max |
0.30~0.60 |
0.025 |
0.025 |
0.25-1.0 |
0.90~1.10 |
| Grade | Tensile Strength, MPa | Yield Strength, MPa | Elongation, % | Hardness, HB |
|---|---|---|---|---|
| T9 | 415 min | 205 min | 30 min | 179 max |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| Outside Diameter | OD Tolerance | WT Tolerance | Ovality Tolerance | Cut Length Tolerance |
| OD≤ 12, 7 mm | ± 0, 13 mm | ± 15 % | – | + 3, 18 mm, – 0 mm |
| 12, 7 mm < OD ≤ 38, 1 mm | ± 0, 13 mm | ± 10 % | max, 1, 65 mm | + 3, 18 mm, – 0 mm |
| 38, 1 mm < OD ≤ 88, 9 mm | ± 0, 25 mm | ± 10 % | max, 2, 41 mm | + 4, 76 mm, – 0 mm |
Jaxon Steel is a trusted manufacturer and supplier of premium Alloy Steel T5 Tubing in Houstan, USA. We specialize in high-quality steel materials and offer a diverse range of products, including Alloy Steel, Carbon Steel, Mild Steel, and Galvanized Steel. Our extensive inventory includes Tubes, Pipes, Flanges, Pipe Fittings, Forged Fittings, Sheets, and Plates. With a commitment to timely delivery and outstanding customer service, we use only the finest raw materials to ensure exceptional performance in demanding industrial applications. Contact us today for all your Alloy Steel T5 Tubing needs!
Alloy Steel T9 Tubing finds its application in industries that need high strength at high temperatures, such as thermal and nuclear power plants, petrochemical industries, and oil refineries. It is widely used in boilers, heat exchangers, steam pipes, and superheaters. Owing to its resistance to high-temperature corrosion and oxidation, it also has applications in chemical processing equipment and high-efficiency furnaces. Its heat resistance, pressure integrity, and long lifespan make T9 tubing a vital component in systems requiring durability and performance under aggressive operating conditions.
Luke Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Houstan, USA.
