API 5L Grade B PSL1 Pipe is mainly made from carbon steel, featuring elements like carbon (up to 0.28%), manganese (between 0.40% and 1.20%), phosphorus (up to 0.030%), and sulfur (up to 0.030%). This combination gives it impressive strength and weldability, making it a great choice for structural and pressure applications. These pipes boast a minimum yield strength of 245 MPa and a tensile strength that falls between 415 and 460 MPa. With solid toughness and resistance to corrosion, API 5L Grade B PSL1 Pipes are perfect for both onshore and offshore projects that require the safe transport of oil, gas, and water.
You’ll find API 5L Grade B PSL1 Pipes widely used in systems for transporting oil and gas, in water distribution networks, and within petrochemical facilities. Their strong mechanical properties make them ideal for long-distance transport under high pressure. These pipes also play a crucial role in power plants, offshore drilling rigs, structural frameworks, and boiler manufacturing. Thanks to their reliability, resistance to corrosion, and ease of welding, they thrive in tough environments. Whether in construction or energy sectors, API 5L Grade B PSL1 Pipes deliver lasting performance and efficiency in fluid and gas transportation systems.
| API 5l Gr B Psl2 ERW and HFW | 1/2” NB – 24” NB |
| API 5L Gr B SAW | 16″ – 100″ NB |
| API 5L Grade B Psl1 LSAW / DSAW | 16’OD TO 54″ OD (8 MM TO 50 MM THK) |
| API 5L Grade B Seamless Pipe (OD) | 21.3 – 660mm ( Inch 1/2″ – 26″) |
| OD | 21.3MM ~ 762MM |
| Killed Carbon Steel API 5L Pipe end | BOE-Beveled One End TOE -Treaded One End, BE -Beveled end, BLE -Bevel large end, BSE -Bevel small end, TBE -Treaded Both Ends, BBE -Bevel both ends, POE -Plain One End, PBE -Plain Both Ends, API 5L Grade B Welded Pipe |
| Wall Thickness of API 5L Grade B Pipe | 4.5mm to 60mm |
| API 5L Grade B Material Cutting Techniques | Sawing, Laser, Burrless Cuts, Tapping, Water-Jet, API 5L Gr B Nace Pipe |
| Different methods used by API 5L Grade B Pipe manufacturers’ | Longitudinally Submerged Arc Welded (LSAW), Cold Drawn Seamless (CDS), 100% X Ray/ Gamma Ray Welded Welded, CDW, Submerged Arc Welded (SAW), Extrusion, Fabricated, Seamless, Electro Fusion Seam Welded (EFSW), Horizontal Submerged Arc Welded (HSAW), Electric Resistance Welded (ERW), Hot Finish Seamless (HFS), API 5L Grade B Schedule 80 Pipe |
| Surface Treatment of API 5L Grb Pipe |
|
| Pipe API 5L Gr B Schedule | SCH-40, SCH-80S, SCH-40S, SCH-10S, SCH-5, SCH-80, SCH160, SCH-XS, SCH-STD, SCH-5S, SCH-10, SCH-XXS, API 5L Gr B Smls Pipe |
| L245 Grade B Pipe Length | 12000mm, 20FT, Single Random Length (SRL), 6000mm, 40FT, DRL, Double Random Length (DRL), 2000mm, Custom Length SRL, 3000mm, API 5L Gr.B PSL2- SAW Pipes |
| Chemical Composition % | ||||||||
| PSL1 | PSL2 | |||||||
| Grade | C (Max.) | Mn(Max.) | P(Max.) | S(Max.) | C (Max.) | Mn(Max.) | P(Max.) | S(Max.) |
| A | 0.22 | 0.90 | 0.03 | 0.03 | 0.22 | 1.20 | 0.025 | 0.015 |
| B | 0.26 | 1.20 | 0.03 | 0.03 | 0.22 | 1.30 | 0.025 | 0.015 |
| X42 | 0.26 | 1.30 | 0.03 | 0.03 | 0.22 | 1.40 | 0.025 | 0.015 |
| X46 | 0.26 | 1.40 | 0.03 | 0.03 | 0.22 | 1.40 | 0.025 | 0.015 |
| X52 | 0.26 | 1.40 | 0.03 | 0.03 | 0.22 | 1.40 | 0.025 | 0.015 |
| X56 | 0.26 | 1.40 | 0.03 | 0.03 | 0.22 | 1.40 | 0.025 | 0.015 |
| X60 | 0.26 | 1.40 | 0.03 | 0.03 | 0.22 | 1.45 | 0.025 | 0.015 |
| X65 | 0.26 | 1.45 | 0.03 | 0.03 | 0.22 | 1.65 | 0.025 | 0.015 |
| X70 | 0.26 | 1.65 | 0.03 | 0.03 | 0.22 | 1.85 | 0.025 | 0.015 |
| PSL 1 | |||||
|---|---|---|---|---|---|
| Grade | Tensile Strength(Min.) | Yield Strength(Min.) | Elongation | ||
| MPa | Ksi | MPa | Ksi | E=1944 A 0.2 /U 0.9 | |
| B | 414 | 60 | 241 | 35 | |
| X52 | 455 | 66 | 359 | 52 | |
| X60 | 434 | 63 | 414 | 60 | |
| X65 | 455 | 66 | 448 | 65 | |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Luke Steel is a top manufacturer and supplier of high-quality API 5L Grade B PSL1 Pipe products in Houstan, USA. Specializing in steel solutions, we provide a wide range of products, including Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel. Our offerings include Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates. Known for our reliable delivery and superior customer service, we are committed to offering top-tier steel materials that ensure durability and performance across a wide range of industrial applications. We strive to meet the highest standards, making us a trusted partner for all your steel needs.
Luke Steel, a leading manufacturer and supplier located in Houston, Houstan, focuses on providing top-notch API 5L Grade B PSL1 Pipes to clients across various industries. Renowned for their strict compliance with international standards, Luke Steel guarantees that each pipe meets the rigorous demands of oil, gas, and water transport systems. With a dedication to precision engineering, timely delivery, and competitive pricing, Luke Steel has earned a solid reputation among industrial clients looking for dependable carbon steel piping solutions. Their API 5L Grade B PSL1 Pipes are trusted for their durability, performance, and cost-effectiveness in essential infrastructure projects.
Luke Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Houstan, USA.
