Luke Steel is a reliable manufacturer and supplier of superior–quality ASME SA 387 Grade 91 Class 1/2 Plates and Sheets, proudly based in Houstan, USA. Known for its precision-engineered alloy steel items, the organization is engaged in servicing critical industries like power generation, petrochemicals, and industrial engineering. With an international quality compliance focus, Luke Steel delivers strong and sturdy materials capable of withstanding extreme pressure and hot temperatures. Supported by technical knowledge and customer-centric strategies, Luke Steel guarantees on-time delivery, tailored solutions, and consistent product quality, becoming a trusted partner in demanding industrial marketplaces.
ASME SA 387 Grade 91 Class 1/2 Sheets and Plates are alloy steels with a complex composition containing chromium (~9%), molybdenum (~1%), vanadium, and niobium. These elements ensure higher creep strength, high-temperature stability, and outstanding oxidation resistance. The plates have good tensile strength, in the range of 585–760 MPa, with Class 2 somewhat higher in strength and yield than Class 1. Their fine-grained, tempered martensitic microstructure provides resilience against long-term exposure to high temperatures and is therefore appropriate for high-stress service conditions in thermal and pressure-intensive industrial processes.
| Standard | ASTM A387 / ASME SA387 |
|---|---|
| Width | 1000mm-3000mm |
| Thickness | 1.0mm – 200mm |
| Production | Hot-Rolled (HR) / Cold-Rolled (CR) |
| Grade | C | Ni | Mn | S | V | Al | Si | Nb | Cr | Mo | Nitrogen | P |
| A387 GR.91 CL.1 & 2 | 0.06-0.15 max | 0.43 max | 0.25-0.66 max | 0.012 max | 0.16-0.27 max | 0.05 max | 0.18-0.56 max | 0.05-0.11 max | 7.90-9.60 max | 0.80-1.10 max | 0.025-0.080 max | 0.025 max |
| Grade | A387 GR.91 CL.1 &2 | |||
| A387 GR.91 CL.1 &2 | Thickness mm | Yield Min Mpa | Tensile Mpa | Elongation Min % |
| t≦50 | 415 | 585-760 | 18 | |
| 50<t≦200 | – | – | – | |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Jaxon Steel is a trusted manufacturer and supplier of high-quality ASME SA 387 Grade 91 Class 1/2 Sheet and Plates in Houstan, USA. We specialize in premium steel products, including Alloy Steel, Carbon Steel, Mild Steel and Galvanized Steel, with a strong focus on Carbon Steel Sheet and Plates. Our extensive inventory also includes Pipes, Tubes, Flanges, Forged Fittings and Bars. Committed to fast delivery and exceptional customer service, we use only the finest raw materials to ensure superior strength, durability and performance for critical industrial applications. Contact us today for all your ASME SA 387 Grade 91 Class 1/2 Sheet and Plates needs!
ASME SA 387 Grade 91 Class 1/2 Plates and Sheets are critical in sectors where there is an urgent need for outstanding resistance to heat, pressure, and chemical corrosion. Such general applications incorporate boilers, pressure vessels, heat exchangers, and steam piping systems in nuclear and thermal power plants. ASME SA 387 Grade 91 Class 1/2 Sheets and Plates are extensively applied in petrochemical plants, oil & gas refineries, and high-pressure process piping. Their superior mechanical characteristics minimize downtime and maintenance, providing long-term operational safety and efficiency. Whether used in reactor manufacture or critical piping systems, Grade 91 plates exhibit unparalleled reliability in severe and high-performance applications.
Luke Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Houstan, USA.
