Luke Steel is a prominent Houston, USA–based manufacturer and supplier of high-grade ASTM A572 Gr 50 Sheets and Plates. We take pride in offering structural-grade steel products that possess superior strength, weldability, and durability. Our A572 Grade 50 products are specifically designed to satisfy the strict demands of contemporary construction and engineering applications. Our products are perfectly suited to be utilized in bridges, buildings, infrastructure, and heavy machinery. Supported by strict following of ASTM specifications and strict quality control, Luke Steel guarantees consistent performance and dependability, which makes us a reliable partner for customers in the construction and industrial industries.
ASTM A572 Gr 50 Plates and Sheets consist of a low-alloy steel composition that contains carbon (maximum 0.23%), manganese (maximum 1.35%), phosphorus (maximum 0.04%), sulfur (maximum 0.05%), silicon (maximum 0.40%), and columbium-vanadium for added strength. These plates provide a minimum yield strength of 345 MPa and tensile strength ranging between 450–620 MPa. With outstanding notch toughness, formability, and weldability, the well-balanced composition renders them suitable for rigorous structural applications where both strength and ductility are needed, even under changing or harsh working conditions.
| Specifications | : | ASME SA572 / ASTM A572 |
|---|---|---|
| Width | : | 1500-4020mm |
| Length | : | 3000-27000mm |
| Thickness | : | 8-300mm |
| Hardness | : | As per ASME A & NACE MR 175 |
| Impact tested | : | Impact tested -52° C |
| Finish | : | Hot rolled plate (HR), Cold rolled sheet (CR) |
| Grade | C | Mn | P | V | Ni | Co | S | Si |
| A572 Grade 50 | 0.23 | 1.35 | 0.04 | 0.06 | 0.015 | 0.05 | 0.05 | 0.4 |
| Grade | Thickness | Yield | Tensile | Elongation |
| A572 Grade 50 | 8mm-200mm | MPa -345 min | MPa – 450 | 18-21% |
| Grade | India IS | England BS | Sweden MNC | Belgium NBN | Europe EN | Russia GOST |
| A572 Grade 50 Plate | FE410WC | 43EE | SS14,14，01 | AE 295 DD | S275 J2G3 Fe430 D2 S275NL |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| GRADE | GAUGE (INCHES) | WIDTH (INCHES) | LENGTH (INCHES) |
| A572 | 0.1875 | 96 | 240/480 |
| A572 | 0.2500 | 60/96/120 | 240/480 |
| A572 | 0.3125 | 60/96/120 | 240/480 |
| A572 | 0.3750 | 60/96/120 | 240/480 |
| A572 | 0.5000 | 60/96/120 | 240/480 |
| A572 | 0.6250 | 60/96/120 | 240/480 |
| A572 | 0.7500 | 60/96/120 | 240/480 |
| A572 | 0.8750 | 60/96/120 | 240/480 |
| A572 | 1.0000 | 60/96/120 | 240/480 |
| A572 | 1.1250 | 60/96/120 | 240/480 |
| A572 | 1.2500 | 60/96/120 | 240/480 |
| A572 | 1.5000 | 60/96/120 | 240/480 |
| A572 | 1.7500 | 60/96/120 | 240/480 |
| A572 | 2.0000 | 60/96/120 | 240/480 |
| A572 | 2.2500 | 96 | 240/480 |
| A572 | 2.5000 | 96 | 240/480 |
| A572 | 2.7500 | 96 | 240/480 |
| A572 | 3.0000 | 96 | 240/480 |
| A572 | 3.2500 | 96 | 240 |
| A572 | 3.5000 | 96 | 240 |
| A572 | 3.7500 | 96 | 240 |
| A572 | 4.0000 | 96 | 240 |
| A572 | 5.0000 | 96 | 240 |
| A572 | 6.0000 | 96 | 240 |
ASTM A572 Gr 50 Plates and Sheets are applied extensively in structural and civil engineering applications that demand high strength with less weight. Some of the major applications are bridge building, skyscrapers, structural frames, railcars carrying freight, cranes, and heavy equipment. Their superior formability and weldability enable complex forming and design flexibility. These plates are further employed in transmission towers, industrial platforms, and equipment that is exposed to dynamic loads and atmospheric environments. With corrosion, stress, and impact resistance, A572 Gr 50 steel is a prime selection for up-to-date infrastructure construction where long-term performance and structural integrity are needed.
