BIRNAR 400 Sheets and Plates are crafted from abrasion-resistant steel, boasting a nominal hardness of 400 HBW. Their typical chemical makeup includes carbon (0.12–0.22%), manganese (1.0–1.6%), silicon (0.2–0.7%), chromium (up to 1.0%), nickel (up to 1.0%), and boron (up to 0.004%). These plates are known for their impressive impact toughness and outstanding wear resistance. When it comes to mechanical properties, they offer tensile strength between 1250–1450 MPa and yield strength exceeding 1000 MPa, along with excellent elongation and formability. BIRNAR 400 is the perfect blend of strength, durability, and wear resistance, making it a go-to choice for demanding industrial applications.
Industries that require high wear resistance and durability frequently turn to BIRNAR 400 Sheets and Plates. You’ll find them in applications like mining equipment, construction machinery, dump truck bodies, crushers, hoppers, and chutes. These plates excel at handling abrasive materials and standing up to mechanical wear in tough working environments. Their impressive strength-to-weight ratio also makes them a great fit for structural components in heavy-duty vehicles and industrial equipment. Plus, they’re commonly used in recycling plants, material handling systems, and quarrying tools. With BIRNAR 400’s remarkable hardness and toughness, you can expect a longer service life, which means less maintenance downtime and improved operational efficiency.
Item: BRINAR 400
Thickness : 5mm to 150mm
Length : 6,000mm to 12,000mm
Width : 1,500mm to 2,500mm
Heat Treatment: N, Q+T
Surface Point : EP, PE, HDP, SMP, PVDF
| C | Si | Mn | P | S | Cr | Ni | Mo | |
| max | 0.2 | 0.5 | 1.7 | 0.015 | 0.005 | 1.5 | 1 | 0.6 |
| Grade | Yield | Tensile | Elongation | Degree | longitudinal |
| Brinar 400 | Min Mpa | Mpa | Min % | -40 | J |
| 1000 | 1250 | 10 | 45 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| 1/8″ | 3/8″ | 3/4″ | 1-1/2″ | 3″ |
| 3/16″ | 1/2″ | 1″ | 2″ | 4″ |
| 1/4″ | 5/8″ | 1-1/4″ | 2-1/2″ | |
| *1/8″ thick plate is available in one size only 60″x 120″. The 3/6″ thick plate is available only as 48″ x 144″ and 96″ x 144″. | ||||
| Thickness | Width | Length |
| 4 | 2000 | 6000 |
| 5 | 2000 | 6000 |
| 6 | 2000 | 6000 |
| 6 | 2500 | 6000 |
| 8 | 2000 | 6000 |
| 8 | 2500 | 6000 |
| 10 | 2000 | 6000 |
| 12 | 2000 | 6000 |
| 15 | 2000 | 6000 |
| 16 | 2000 | 6000 |
| 20 | 2000 | 6000 |
| 25 | 2000 | 6000 |
| 32 | 2000 | 6000 |
| 40 | 2000 | 6000 |
| 50 | 2000 | 6000 |
| 60 | 1800 | 3400 |
