Luke Steel stands out as a top-notch manufacturer and supplier located in Houston, Houstan, with a focus on high-quality Carbon Steel A105 Forged Fittings. Known for our reliability and excellence, we pride ourselves on delivering precision-engineered forged fittings that meet the rigorous demands of various industries. Our products are crafted from premium-grade raw materials and utilize cutting-edge forging technology, ensuring they boast superior strength, durability, and resistance to wear and pressure. With a commitment to quality and timely delivery, we cater to clients in the oil & gas, petrochemical, and power generation sectors, providing products that meet international standards like ASTM A105 and ASME B16.11.
When it comes to Carbon Steel A105 Forged Fittings, they primarily consist of carbon (up to 0.35%), manganese (0.60–1.05%), phosphorus (up to 0.035%), sulfur (up to 0.040%), along with trace amounts of silicon and copper. These fittings are known for their impressive mechanical properties, featuring a minimum tensile strength of 485 MPa and a yield strength of 250 MPa. They also offer good ductility, impact resistance, and hardness. Heat-treated for enhanced performance, A105 forged fittings are designed to withstand high pressure and temperature, making them perfect for critical industrial applications. Their fine grain structure contributes to their strength and fatigue resistance.
Standard : ASTM A105 / ASME SA 105
Dimensions : ASME/ANSI 16.11, MSS SP-79, 83, 95, 97, BS 3799
Size : 1/8″ NB to 4″ NB
Type : Socketweld Fittings, Screwed-Threaded Fittings (NPT or PT Type)
Rating Pressure : Threaded End – 2000 /3000/ 6000 LBS. Socket-weld End – 3000 / 6000/ 9000 LBS.
| Grade | C | Si | Mn | P | S | Mo | Ni | Cr | Cu | V |
| A105 | 0.35 | 0.10–0.35 | 0.60–1.05 | 0.035 | 0.040 | 0.12 | 0.40 | 0.30 | 0.40 | 0.08 |
| Grade | Yield Strength, Min (MPa) | Tensile Strength, Min (MPa) | Elongation, min, % |
| A105 | 250 | 485 | 30 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| ASME B16.11 | Factory-Made Wrought Socketweld Fittings | CS A105 Forged Screwed Elbows, Street Elbow, A105 Carbon Steel Screwed Unequal Tee, Steel Straight Tee, Carbon Steel A105 Reducing Coupling, A105 Carbon Steel Hex Plug, Forged Straight Tees, Socket Weld Pipe Cap, Forged Pipe Cap, Equal Crossess, CS A105 Threaded Bushing, A105 Carbon Steel Screwed Caps, Swedge Nipples |
| MSS-SP-79 | standard Practice covers ratings, tolerances, finish, dimensions, marking and material requirements for socket-welding | Carbon Steel A105 Barrel Nipples, CS A105 Forged Threaded Boss, A105 Carbon Steel Forged Hex Head Bull Plugs |
| MSS-SP-83 | Forged and Fabricated Socket-Welding Fittings for Low Pressure, Corrosion Resistant Applications | Carbon Steel A105 High Quality Socket weld 90° Elbow, Straight and Reducing-on-the-Tees, Forged 45° Short Radius Elbow, CS A105 caps, 3000LB Socket Weld Cross |
| MSS-SP-95 | Integrally Reinforced Forged Fittings – Socket Welding, Threaded, and Buttwelding Ends | CS A105 Socket weld Long Radius 90 Degree Elbows, Reducing Nipple, Socketweld Bushing, Threaded Plug, End Pipe caps, Carbon Steel A105 Coupling |
Carbon Steel A105 Forged Fittings find extensive use in high-pressure piping systems and critical fluid handling applications. Their sturdy design and high mechanical strength make them a go-to choice for the oil & gas, petrochemical, chemical processing, and power generation industries. These fittings are commonly employed to connect pipelines, regulate flow, and ensure leak-proof performance even under extreme conditions. Suitable for both above-ground and underground installations, they are often found in refineries, offshore platforms, heat exchangers, and boiler systems. Their ability to endure thermal cycling and resist corrosion further boosts their effectiveness in challenging industrial environments.
Luke Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Houstan, USA.
