Luke Steel is a well-respected manufacturer and supplier of Carbon Steel API X65 5L PSL 1 Pipes, proudly based in Houston, USA. Known for delivering top-notch steel products, Luke Steel provides reliable and efficient pipeline solutions tailored for the oil, gas, and petrochemical industries. Our API X65 pipes are crafted in line with API 5L PSL 1 standards, guaranteeing consistent performance, structural integrity, and adherence to industry regulations. With cutting-edge manufacturing techniques and a strong focus on customer satisfaction, Luke Steel caters to clients throughout the United States and around the world, supporting vital infrastructure projects with prompt delivery and outstanding service.
Carbon Steel API X65 5L PSL 1 Pipes primarily consist of iron, with a carbon content of about 0.05%–0.09%, along with 1.2%–1.45% manganese and trace amounts of phosphorus and sulfur. This specific composition strikes a perfect balance between strength, weldability, and toughness. These pipes boast a minimum yield strength of 450 MPa and a tensile strength that ranges from 535–760 MPa. Designed for durability and resistance to stress corrosion, API X65 pipes are ideal for challenging environments. Their mechanical properties make them suitable for high-pressure flow systems, ensuring reliable long-term performance even in tough pipeline operations.
| Standard | ISO 3183 L450/ API 5L X65 |
| Grade of material | X65 / L450 (N, M, Q, R) |
| PSL Level | |
| API 5L X65 PSL1 Seamless Pipe (OD) | 21.3 – 660mm ( Inch 1/2” – 26”) |
| X65 Steel LSAW / DSAW | 16’OD TO 54″ OD (8 MM TO 50 MM THK) |
| X65 Carbon Steel SAW | 16″ – 100″ NB |
| API 5L X65 PSL1 ERW and HFW | 1/2” NB – 24” NB |
| Coating for API 5L X65 PSL1 Line Pipe | 3PP, Anti-Rust Oil, CRA clad, FBE, lined pipe, Varnished, Black Painting, 3PE, 3LPE, Galvanized, |
| API 5L Grade X65 Pipe end | Cut Grooves, Square Cut, Grooved, Vibrator Grinding, Plain end (PE), Chamfering, Coupling, Screwed, Pub Joints, Deburring, Thread Cutting, Flanged Ends, Socket, Squared Ends, Threaded Ends (Male & Female), Buttweld, Beveled End (BE) |
| Cutting Facility | Laser Cutting, Sawing, Tapping, Water Jet Cutting |
| Equivalent Standards | JIS, DIN, NFA, BS, CSA, GOST, AWWA, KS, UNI, AISI, IS, EN, API, SAE, ANSI, ISO, ASTM, GB, SS |
| Grade X65 PSL1 Pipe Length | DRL, SRL, 20FT, 40FT, Single Random Length (SRL), Double Random Length (DRL), and Fixed Length 5.8 Meter, 12.0 Meters (40FT), 6.0 Meters (20FT), 11.8 Meters, |
| API 5L X65 Wall Thickness | SCH-STD, SCH160, SCH80, SCH-XXS, SCH-XS, SCH40 |
| Manufacturing process | Welded, Seamless, Electro Fusion Seam Welded (EFSW), Hot Finish Seamless (HFS), Longitudinally Submerged Arc Welded (LSAW), Cold Drawn Seamless (CDS), Electric Resistance Welded (ERW), Horizontal Submerged Arc Welded (HSAW), Extrusion, Submerged Arc Welded (SAW) |
| Mass fraction, based upon heat and product analysis a | |||||||
| CS PIPE | |||||||
| C | Mn | P | S | V | Nb | Ti | |
| maxb | max.b | min. | max. | max. | max. | max. | max. |
| 0.28e | 1.40e | – | 0.030 | 0.030 | f | f | f |
| Y.S | T.S | ELONGATION |
| Mpa(psi) | Mpa(psi) | |
| min | min | min |
| 415(60 200) | 520(75 400) | F |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| API 5L X65 Pipe types | API 5L X65 Pipe Size (mm) | Tolerances | |
|---|---|---|---|
| Hot rolled API 5L X65 Seamless Pipe | OD | <50 | ±0.50mm |
| ≥50 | ±1% | ||
| WT | <4 | ±12.5% | |
| ≥4～20 | +15%, -12.5% | ||
| >20 | ±12.5% | ||
| Cold drawn API 5L X65 Seamless Pipe | OD | 6～10 | ±0.20mm |
| 10～30 | ±0.40mm | ||
| 30～50 | ±0.45 | ||
| >50 | ±1% | ||
| WT | <1 | ±0.15mm | |
| >1～3 | + 15%, – 10% | ||
| >3 | + 12.5%, – 10% | ||
Luke Steel is a leading supplier of high-quality Carbon Steel API X65 5L PSL 1 Pipes products in Houstan, USA. We focus on steel solutions and offer a variety of products. This includes Carbon Steel, Alloy Steel, Mild Steel, and Galvanized Steel. Our products are Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets, and Plates. We are known for our good delivery and excellent customer care. We aim to provide strong and durable steel materials for many industrial uses. We work hard to meet high standards, making us a trusted partner for your steel needs.
Carbon Steel API X65 5L PSL 1 Pipes are extensively utilized for transporting oil, gas, and water over long distances in both onshore and offshore pipeline systems. They play a crucial role in the energy sector due to their impressive strength, resistance to cracking, and ability to endure harsh environmental conditions. Additionally, these pipes find applications in structural and mechanical projects that require strong, corrosion-resistant materials. With their excellent weldability and strength, API X65 pipes are a dependable choice for large-scale infrastructure initiatives, including refineries, power plants, and petrochemical facilities.
