Luke Steel is a reputable manufacturer and supplier of Carbon Steel API X70 5L PSL 1 Pipes, proudly based in Houston, USA. Renowned for providing top-notch steel products, Luke Steel specializes in delivering reliable and high-performance pipeline solutions designed to meet the demanding needs of the oil, gas, and petrochemical sectors. Our API X70 pipes are crafted to adhere to API 5L PSL 1 standards, guaranteeing consistency, safety, and quality. With a strong emphasis on timely delivery and customer satisfaction, Luke Steel distributes Carbon Steel API X70 pipes throughout the U.S. and internationally, supporting critical pipeline infrastructure and energy sector projects.
Carbon Steel API X70 5L PSL 1 Pipes are primarily made of iron, containing about 0.04%–0.10% carbon, 1.0%–1.5% manganese, along with trace amounts of phosphorus and sulfur. This specific composition results in a high strength-to-weight ratio and excellent weldability. These pipes boast a minimum yield strength of 485 MPa and a tensile strength ranging from 570 to 760 MPa, making them perfect for high-pressure pipeline operations. API X70 pipes are known for their outstanding toughness and resistance to crack propagation, making them suitable for cold and harsh environments, which is essential for the long-distance transport of oil and gas.
| X70 LSAW / DSAW | 16’OD TO 54″ OD (8 MM TO 50 MM THK) |
| Grade of material | X70 / L485 (N, M, Q, R) |
| Standard | ISO 3183 L485/ API 5L X70 |
| API 5L X70 ERW and HFW | 1/2” NB – 24” NB |
| API 5L Gr X70 Seamless Pipe (OD) | 21.3 – 660mm ( Inch 1/2” – 26”) |
| X70 Steel SAW | 16″ – 100″ NB |
| API 5L X70 PSL1 Pipe end | Flanged Ends, Buttweld, Square Cut, Coupling, Pub Joints, Thread Cutting, Cut Grooves, Deburring, Squared Ends, Beveled End (BE), Vibrator Grinding, Socket, Grooved, Screwed, Chamfering, Plain end (PE), Threaded Ends (Male & Female) |
| Manufacturing process | Welded, Seamless, Longitudinally Submerged Arc Welded (LSAW), Electro Fusion Seam Welded (EFSW), Submerged Arc Welded (SAW), Cold Drawn Seamless (CDS), Horizontal Submerged Arc Welded (HSAW), Extrusion, Hot Finish Seamless (HFS), Electric Resistance Welded (ERW) |
| API 5L X70 Wall Thickness | SCH-XXS, SCH160, SCH-XS, SCH40, SCH-STD, SCH80 |
| Equivalent Standards | KS, AISI, ISO, BS, SS, EN, JIS, AWWA, CSA, GOST, SAE, GB, ANSI, NFA, ASTM, API, DIN, IS, UNI |
| PSL Level | |
| X70 Carbon Steel Pipe Length | DRL, SRL, 20FT, 40FT, Single Random Length (SRL), Double Random Length (DRL), and Fixed Length 5.8 Meter, 12.0 Meters (40FT), 6.0 Meters (20FT), 11.8 Meters, |
| Mass fraction, based upon heat and product analysis a | |||||||
| Carbon Steel PIPE | |||||||
| C | Mn | P | S | V | Nb | Ti | |
| maxb | max.b | min. | max. | max. | max. | max. | max. |
| 0.28e | 1.40e | – | 0.030 | 0.030 | f | f | f |
| Y.S | T.S | ELONGATION |
| Mpa(psi) | Mpa(psi) | |
| min | min | min |
| 485(70 300) | 570(82 700) | F |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| NB | DN | OD (inches) | API 5L X 70 Carbon Steel Seamless Pipe Schedule | |||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| SCH 5 | SCH 10 | SCH 20 | SCH 30 | SCH 40 | SCH 60 | SCH 80 | SCH 100 | SCH 120 | SCH 160 | |||
| 3/4″ | 20 | 1.05 | 0.065 | 0.11 | x | 0.095 | 0.113 | x | x | 0.17 | x | 0.219 |
| 1″ | 25 | 1.315 | 0.065 | 0.11 | x | 0.114 | 0.133 | x | x | 0.2 | x | 0.25 |
| 1.1/2″ | 40 | 1.9 | 0.065 | 0.11 | x | 0.125 | 0.145 | x | x | 0.225 | x | 0.281 |
| 2″ | 50 | 2.375 | 0.065 | 0.12 | x | x | 0.154 | x | x | 0.25 | x | 0.344 |
| 2.1/2″ | 65 | 2.875 | 0.083 | 0.12 | x | x | 0.203 | x | x | 0.3 | x | 0.375 |
| 3″ | 80 | 3.5 | 0.083 | 0.12 | x | x | 0.216 | x | x | 0.35 | x | 0.438 |
| 4″ | 100 | 4.5 | 0.083 | 0.12 | x | x | 0.237 | x | x | 0.437 | x | 0.531 |
| 5″ | 125 | 5.563 | 0.109 | 0.12 | x | x | 0.258 | x | x | 0.5 | x | 0.625 |
| 6″ | 150 | 6.625 | 0.109 | 0.13 | x | x | 0.28 | x | x | 0.562 | x | 0.719 |
| 8″ | 200 | 8.625 | 0.109 | 0.15 | 0.25 | 0.277 | 0.322 | 0.406 | 0.593 | 0.718 | 0.812 | 0.906 |
| 10″ | 250 | 10.75 | 0.134 | 0.17 | 0.25 | 0.307 | 0.365 | 0.5 | 0.718 | 0.843 | 1.0 | 1.125 |
| 12″ | 300 | 12.75 | 0.165 | 0.18 | 0.25 | 0.33 | 0.406 | 0.5 | 0.843 | 1.0 | 1.125 | 1.312 |
Luke Steel is a leading supplier of high-quality Carbon Steel API X70 5L PSL 1 Pipes products in Houstan, USA. We focus on steel solutions and offer a variety of products. This includes Carbon Steel, Alloy Steel, Mild Steel, and Galvanized Steel. Our products are Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets, and Plates. We are known for our good delivery and excellent customer care. We aim to provide strong and durable steel materials for many industrial uses. We work hard to meet high standards, making us a trusted partner for your steel needs.
Carbon Steel API X70 5L PSL 1 Pipes are mainly utilized for transporting oil, natural gas, and various fluids in high-pressure pipeline systems. Their robust strength and ability to withstand extreme temperatures and pressures make them ideal for both offshore and onshore pipeline infrastructure. These pipes find extensive use in the petroleum, natural gas, chemical, and power generation industries. Additionally, they are employed in structural applications where high strength and durability are paramount. Their compliance with API standards ensures reliability and performance in large-scale transmission projects and developments within the energy sector.
