Luke Steel is a reputable manufacturer and supplier located in Houston, Houstan, with a focus on high-quality Carbon Steel BS1387 Pipes. Known for its dedication to excellence, Luke Steel delivers durable and dependable piping solutions that adhere to international standards, catering to a variety of industrial applications. With a strong emphasis on customer satisfaction, the company provides products in multiple sizes and finishes, making them suitable for structural, mechanical, and plumbing needs. Supported by a talented team and advanced manufacturing techniques, Luke Steel guarantees consistent quality, timely delivery, and competitive pricing to meet the diverse requirements of both U.S. and global markets.
Carbon Steel BS1387 Pipes are generally made from iron with a carbon content between 0.12% and 0.20%, along with small amounts of manganese, phosphorus, and sulfur. This blend offers a great balance of strength and ductility. In terms of mechanical properties, these pipes boast a minimum tensile strength of about 330–430 MPa and a yield strength of roughly 195 MPa. They also exhibit good elongation (around 20%) and impact resistance, making them ideal for low- to medium-pressure applications. For enhanced corrosion resistance in tough environments, the pipes can be galvanized.
| BS1387 | |||
| C | Mn | P | S |
| S,W | 0.2 | 1.2 | 0.045Max |
| BS1387 | Yield point Min Mpa | Tensile Strength Mpa | Elongation (%) |
| ≥195 | 325~460 | ≥20 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Jaxon Steel is a leading manufacturer and supplier of high-quality Carbon Steel BS1387 Pipe products in Houstan, USA. Specializing in steel solutions, we offer a wide range of products, including Carbon Steel, Alloy Steel, Mild Steel, and Galvanized Steel. Our product lineup features Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets, and Plates. Renowned for our reliable delivery and exceptional customer service, we are dedicated to providing top-grade steel materials that ensure durability and performance in various industrial applications. Jaxon Steel is your trusted partner for all your Carbon Steel BS1387 Pipe needs.
| Class | Nominal Diameter (DN) mm | Designation of thread Inch | Outside diameter | Thickness mm | Mass of black tube | ||
| Max mm | Min mm | Plain end kg/m | Screwed and socketed kg/m | ||||
| Light | 15 | 1/2 | 21.4 | 21.0 | 2.0 | 0.947 | 0.956 |
| 20 | 3/4 | 26.9 | 26.4 | 2.3 | 1.38 | 1.39 | |
| 25 | 1 | 33.8 | 33.2 | 2.6 | 1.98 | 2.00 | |
| 32 | 1 1/4 | 42.5 | 41 .9 | 2.6 | 2.54 | 2.57 | |
| 40 50 | 1 1/2 2 | 48.4 60.2 | 47.8 59.60 | 2.9 2.9 | 3.23 4.08 | 3.27 4.15 | |
| 65 | 2 1/2 | 76.0 | 75.2 | 3.2 | 5.71 | 5.83 | |
| 80 | 3 | 88.7 | 87.9 | 3.2 | 6.72 | 6.89 | |
| 100 | 4 | 113.9 | 113.0 | 3.6 | 9.75 | 10.0 | |
| Medium | 15 | 1/2 | 21.7 | 21.1 | 2.6 | 1.21 | 1.22 |
| 20 | 3/4 | 27.2 | 26.6 | 2.6 | 1.56 | 1.57 | |
| 25 | 1 | 34.2 | 33.4 | 3.2 | 2.41 | 2.43 | |
| 32 | 1 1/4 | 42.9 | 42.1 | 3.2 | 3.10 | 3.13 | |
| 40 | 1 1/2 | 48.4 | 48.0 | 3.2 | 3.57 | 3.61 | |
| 50 | 2 | 60.8 | 59.8 | 3.6 | 5.03 | 5.10 | |
| 65 | 2 1/2 | 76.6 | 75.4 | 3.6 | 6.43 | 6.55 | |
| 80 | 3 | 89.5 | 88.1 | 4.0 | 8.37 | 8.54 | |
| 100 | 4 | 114.9 | 113.3 | 4.5 | 12.2 | 12.5 | |
| 125 | 5 | 140.6 | 138.7 | 5.0 | 16.6 | 17.1 | |
| 150 | 6 | 166.1 | 164.1 | 5.0 | 19.7 | 20.3 | |
| Heavy | 15 | 1/2 | 21.7 | 21.1 | 3.2 | 1.44 | 1.45 |
| 20 | 3/4 | 27.2 | 26.6 | 3.2 | 1.87 | 1.88 | |
| 25 | 1 | 34.2 | 33.4 | 4.0 | 2.94 | 2.96 | |
| 32 | 1 1/4 | 42.9 | 42.1 | 4.0 | 3.80 | 3.83 | |
| 40 | 1 1/2 | 48.8 | 48.0 | 4.0 | 4.38 | 4.42 | |
| 50 | 2 | 60.8 | 59.8 | 4.5 | 6.19 | 6.26 | |
| 65 | 2 1/2 | 76.6 | 75.4 | 4.5 | 7.93 | 8.05 | |
| 80 | 3 | 89.5 | 88.1 | 5.0 | 10.3 | 10.5 | |
| 100 | 4 | 114.9 | 113.3 | 5.4 | 14.5 | 14.8 | |
| 125 | 5 | 140.6 | 138.7 | 5.4 | 17.9 | 18.4 | |
| 150 | 6 | 166.1 | 164.1 | 5.4 | 21.3 | 21.9 | |
| NOTES: 1) Dimensions and masses are accordance with ISO R65 2) Hydrostatic test pressure 50 kg/cm2 | |||||||
These Carbon Steel BS1387 Pipes are widely utilized across various industries due to their strength, durability, and cost-effectiveness. You’ll find them in water supply systems, gas pipelines, fire sprinkler systems, and HVAC installations. In construction, they serve as structural support in scaffolding, fencing, and frameworks. The oil and gas industry relies on these pipes for low-pressure transmission lines, while manufacturing sectors use them in machinery and equipment fabrication. Plus, their availability in galvanized form makes them perfect for outdoor and corrosive settings, ensuring long-lasting performance in both residential and commercial infrastructure projects. Their versatility truly makes them a go-to choice around the globe.
Luke Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Houstan, USA.
