Luke Steel is a well-established producer and supplier of top–grade Carbon Steel BS3601 Pipes, which is situated in Houston, USA. Based on unwavering technical know-how, accurate production, and British standard compliance, Luke Steel serves a variety of industrial requirements with reliable carbon steel piping solutions. Due to its high strength, durabilty, and economy, BS3601 pipes are broadly used in engineering and mechanical industries. By using rigorous quality control measures and timely delivery, Luke Steel has evolved as a reliable partner for clients looking for reliable pipe products and cater to domestic and export markets alike with professionalism and consistency.
Carbon Steel BS3601 Pipes consist mostly of carbon (maximum 0.20%), manganese (maximum 1.2%), and traces of phosphorus and sulfur (each maximum 0.05%), with the base element being iron. These pipes are designed to have high weldability, ductility, and strength. Their average yield strength is about 235 MPa with tensile strength ranging from 360–500 MPa, varying with the wall thickness and diameter. The material has good formability and a moderate pressure capacity, and thus it is used for bending, shaping, and service under moderate temperature and pressure conditions.
| Dimensions | ASTM, ASME and API |
| Thickness | 50mm to 7.00mm, custom OD and thickness available on request |
| End | Plain End, Beveled End, Treaded |
| Length | Single Random, Double Random & Required Length, Custom Size – according to customer’s requirement |
| Schedules | SCH 40, SCH 80, SCH 160, SCH XS, SCH XXS, All Schedules |
| Types | Seamless / ERW / Welded / Fabricated / CDW |
| Outer Diameter | 19.05mm to 127mm |
| Wall Thickness | 0.8mm to 6.0mm |
| Length | 6mtr/ 12mtr or Cut to Length |
| Capacity | 7000 Mt/Month |
Grade | Mfg. Process | Chemical Composition(%) | ||||||||
C | Si | Mn | P | S | Ni | Cr | Mo | Others | ||
BW320 | B | 0.16Max | – | 0.30~0.70 | 0.040Max | 0.040Max | – | – | – | – |
ERW320 | E | 0.16Max | – | 0.30~0.70 | 0.040Max | 0.040Max | – | – | – | – |
ERW360 | E | 0.17Max | 0.35Max | 0.40~0.80 | 0.040Max | 0.050Max | – | – | – | – |
ERW430 | E | 0.21Max | 0.35Max | 0.40~1.20 | 0.040Max | 0.040Max | – | – | – | – |
S360 | S | 0.17Max | 0.35Max | 0.40~0.80 | 0.040Max | 0.040Max | – | – | – | t 16mmMax 16mm<t 40mmMAX 40mm<t 65mmMax |
S430 | S | 0.21Max | 0.35Max | 0.40~1.20 | 0.040Max | 0.040Max | – | – | – | t 16mmMax 16mm<t 40mmMAX 40mm<t 65mmMax |
SAW430 | A | 0.25Max | 0.50Max | 1.20Max | 0.040Max | 0.040Max | – | – | – | t 16mmMax 16mm<t 40mmMAX 40mm<t 65mmMax |
|
Grade
|
Tensile Test MPa or N/mm2 |
Remaks (Similar to JIS) |
Possibility Temperature |
|
|
Min Yield point |
Tensile Strength |
|||
|
BW320 |
195 |
320~460 |
– |
|
|
ERW320 |
195 |
320~460 |
– |
|
|
ERW360 |
235 |
360~500 |
(STPG370) |
|
|
ERW430 |
195 |
430~570 |
(STPG410) |
|
|
S360 |
235
225
215 |
360~550 |
(STPG310) |
|
|
S430 |
275
265
255 |
430~570 |
(STPG410) |
|
|
SAW430 |
275
265
255 |
430~570 |
(STPY400) |
|
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| Nominal Pipe Size (inches) | Outer Diameter (mm) | Wall Thickness (mm) | Weight (kg/m) |
|---|---|---|---|
| 1/2 | 21.3 | 2.11 | 1.21 |
| 3/4 | 26.7 | 2.11 | 1.62 |
| 1 | 33.4 | 2.77 | 2.49 |
| 1 1/4 | 42.2 | 3.56 | 3.74 |
| 1 1/2 | 48.3 | 3.68 | 4.46 |
| 2 | 60.3 | 3.91 | 5.71 |
| 3 | 88.9 | 5.49 | 11.29 |
| 4 | 114.3 | 6.02 | 16.07 |
| 6 | 168.3 | 7.11 | 28.26 |
Jaxon Steel is a leading manufacturer and exporter of high-quality Carbon Steel BS3601 Pipes in Houstan, USA. We offer a comprehensive range of steel solutions, including Carbon Steel, Alloy Steel, Mild Steel, and Galvanized Steel. Our product portfolio includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets, and Plates. Known for our reliability and outstanding customer service, we are dedicated to delivering top-tier steel products designed for demanding industrial applications, ensuring long-lasting durability and superior performance. Jaxon Steel is your trusted partner for all Carbon Steel BS3601 Pipe needs.
Carbon Steel BS3601 Pipes have extensive applications across various industries such as oil and gas, petrochemicals, water treatment plants, and construction. The pipes are perfect for conveying fluids and gases within low-pressure systems, delivering great performance in both above-ground and buried installations. It is used in boiler systems, HVAC pipes, structural support, and general engineering. Their resistance to corrosion (where coated), coupled with strength and affordability, establishes them as a cost-effective option for utility and infrastructure projects. In commercial structures or industrial plants, BS3601 pipes offer long-term reliability and performance in harsh service conditions.
