Based in Houston, Texas, Luke Steel is a top producer and supplier of carbon steel BS3603 pipes. Luke Steel is well-known for their excellent quality standards and precise engineering, and they provide high-performance piping solutions for both commercial and industrial applications. Their BS3603 pipes are designed to satisfy exacting international standards, guaranteeing dependability, longevity, and superior resistance to corrosion and stress. Luke Steel facilitates prompt delivery both domestically and internationally with a customer-focused strategy and a large inventory. Luke Steel provides reliable carbon steel piping solutions to the oil and gas, petrochemical and power generation industries.
Premium carbon steel that satisfies BS3603 requirements is used in the production of Carbon Steel BS3603 Pipes. Carbon (up to 0.3%), manganese (up to 1.5%), phosphorus (≤ 0.04%), and sulphur (≤ 0.05%) make up their usual chemical composition. These pipes have exceptional mechanical qualities, such as a minimum elongation of 20%, a yield strength of at least 245 MPa, and a tensile strength ranging from 410 to 560 MPa. They are perfect for high-stress and high-temperature environments because of their exceptional toughness, weldability, and pressure resistance.
| Dimensions | ASTM, ASME and API |
| Thickness | 50mm to 7.00mm, custom OD and thickness available on request |
| End | Plain End, Beveled End, Treaded |
| Length | Single Random, Double Random & Required Length, Custom Size – according to customer’s requirement |
| Schedules | SCH 40, SCH 80, SCH 160, SCH XS, SCH XXS, All Schedules |
| Types | Seamless / ERW / Welded / Fabricated / CDW |
| Outer Diameter | 19.05mm to 127mm |
| Wall Thickness | 0.8mm to 6.0mm |
| Length | 6mtr/ 12mtr or Cut to Length |
| Capacity | 7000 Mt/Month |
Grade | Mfg. Process | Chemical Composition(%) | ||||||||
C | Si | Mn | P | S | Ni | Cr | Mo | Others | ||
BW320 | B | 0.16Max | – | 0.30~0.70 | 0.040Max | 0.040Max | – | – | – | – |
ERW320 | E | 0.16Max | – | 0.30~0.70 | 0.040Max | 0.040Max | – | – | – | – |
ERW360 | E | 0.17Max | 0.35Max | 0.40~0.80 | 0.040Max | 0.050Max | – | – | – | – |
ERW430 | E | 0.21Max | 0.35Max | 0.40~1.20 | 0.040Max | 0.040Max | – | – | – | – |
S360 | S | 0.17Max | 0.35Max | 0.40~0.80 | 0.040Max | 0.040Max | – | – | – | t 16mmMax 16mm<t 40mmMAX 40mm<t 65mmMax |
S430 | S | 0.21Max | 0.35Max | 0.40~1.20 | 0.040Max | 0.040Max | – | – | – | t 16mmMax 16mm<t 40mmMAX 40mm<t 65mmMax |
SAW430 | A | 0.25Max | 0.50Max | 1.20Max | 0.040Max | 0.040Max | – | – | – | t 16mmMax 16mm<t 40mmMAX 40mm<t 65mmMax |
Grade
| Tensile Test MPa or N/mm2 | Remaks (Similar to JIS) | Possibility Temperature | |
Min Yield point | Tensile Strength | |||
BW320 | 195 | 320~460 | – | |
ERW320 | 195 | 320~460 | – | |
ERW360 | 235 | 360~500 | (STPG370) | |
ERW430 | 195 | 430~570 | (STPG410) | |
S360 | 235 225 215 | 360~550 | (STPG310) | |
S430 | 275 265 255 | 430~570 | (STPG410) | |
SAW430 | 275 265 255 | 430~570 | (STPY400) | |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Jaxon Steel is one of the major manufacturers and exporters of Carbon Steel BS3603 Pipes in Houstan, USA. We have a variety of steel solutions: Carbon Steel, Alloy Steel, Mild Steel, and Galvanized Steel. Our product portfolio ranges from Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets, and Plates. We are highly regarded for reliability and excellent service, committed to offering superior-quality steel products well suited for critical industrial applications; these are very durable and therefore guarantee optimal performance. Jaxon Steel is a company you can count on regarding your Carbon Steel BS3603 Pipe needs.
BS3603 Carbon Steel In many different industries, pipes are utilised extensively in high-temperature and high-pressure applications. They are employed in the transportation of petroleum products, natural gas, and crude oil in the oil and gas industry. Because of their high thermal resistance, power plants use them in heat exchangers and boiler tubes. They are used in fluid handling systems and process piping in the chemical and petrochemical industries. They are also used in structural applications, mechanical engineering, and shipbuilding, where durability and strength are essential. They are a favoured option in crucial operations due to their adaptability, affordability, and adherence to global standards.
Luke Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Houstan, USA.
