Luke Steel is a reputable manufacturer and supplier located in Houston, Houstan, known for its top-notch Carbon Steel BS3606 Pipes that cater to a variety of industrial needs. With a strong dedication to quality and adherence to international standards, Luke Steel delivers robust and dependable carbon steel piping solutions for clients in industries such as oil & gas, power generation, construction, and manufacturing. Utilizing cutting-edge technology and strict quality control measures, the company guarantees that each BS3606 pipe provides outstanding performance, precise dimensions, and a long lifespan, making Luke Steel a go-to partner in the global steel supply chain.
The Carbon Steel BS3606 Pipe is mainly made up of iron and carbon, with small amounts of elements like manganese and silicon added to enhance its strength and toughness. These pipes boast impressive mechanical properties, including a tensile strength ranging from 410 to 560 MPa, a yield strength of about 245 MPa, and an elongation exceeding 20%, which ensures good ductility and impact resistance. This combination of characteristics makes them suitable for both structural applications and high-pressure services, all while maintaining reliability and resistance to stress across varying temperature conditions.
| Dimensions | ASTM, ASME and API |
| Thickness | 50mm to 7.00mm, custom OD and thickness available on request |
| End | Plain End, Beveled End, Treaded |
| Length | Single Random, Double Random & Required Length, Custom Size – according to customer’s requirement |
| Schedules | SCH 40, SCH 80, SCH 160, SCH XS, SCH XXS, All Schedules |
| Types | Seamless / ERW / Welded / Fabricated / CDW |
| Outer Diameter | 19.05mm to 127mm |
| Wall Thickness | 0.8mm to 6.0mm |
| Length | 6mtr/ 12mtr or Cut to Length |
| Capacity | 7000 Mt/Month |
|
Grade |
Mfg. Process |
Chemical Composition(%) | ||||||||
|
C |
Si |
Mn |
P |
S |
Ni |
Cr |
Mo |
Others |
||
|
BW320 |
B |
0.16Max |
– |
0.30~0.70 |
0.040Max |
0.040Max |
– |
– |
– |
– |
|
ERW320 |
E |
0.16Max |
– |
0.30~0.70 |
0.040Max |
0.040Max |
– |
– |
– |
– |
|
ERW360 |
E |
0.17Max |
0.35Max |
0.40~0.80 |
0.040Max |
0.050Max |
– |
– |
– |
– |
|
ERW430 |
E |
0.21Max |
0.35Max |
0.40~1.20 |
0.040Max |
0.040Max |
– |
– |
– |
– |
|
S360 |
S |
0.17Max |
0.35Max |
0.40~0.80 |
0.040Max |
0.040Max |
– |
– |
– |
t 16mmMax 16mm<t 40mmMAX 40mm<t 65mmMax |
|
S430 |
S |
0.21Max |
0.35Max |
0.40~1.20 |
0.040Max |
0.040Max |
– |
– |
– |
t 16mmMax 16mm<t 40mmMAX 40mm<t 65mmMax |
|
SAW430 |
A |
0.25Max |
0.50Max |
1.20Max |
0.040Max |
0.040Max |
– |
– |
– |
t 16mmMax 16mm<t 40mmMAX 40mm<t 65mmMax |
Grade
| Tensile Test MPa or N/mm2 | Remaks (Similar to JIS) | Possibility Temperature | |
Min Yield point | Tensile Strength | |||
BW320 | 195 | 320~460 | – | |
ERW320 | 195 | 320~460 | – | |
ERW360 | 235 | 360~500 | (STPG370) | |
ERW430 | 195 | 430~570 | (STPG410) | |
S360 | 235 225 215 | 360~550 | (STPG310) | |
S430 | 275 265 255 | 430~570 | (STPG410) | |
SAW430 | 275 265 255 | 430~570 | (STPY400) | |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| Outer Diameter (OD) | Wall Thickness (WT) | Length |
|---|---|---|
| 6mm – 25mm | 1mm – 3mm | Up to 6 meters |
| 26mm – 50mm | 3mm – 6mm | Up to 9 meters |
| 51mm – 150mm | 6mm – 12mm | Up to 12 meters |
| 151mm – 300mm | 12mm – 25mm | Customizable |
| 301mm – 508mm | 25mm – 50mm | Customizable |
Jaxon Steel is a leading manufacturer and exporter of Carbon Steel BS3606 Pipes in Houstan, USA. We offer a vast array of steel solutions, including Carbon Steel, Alloy Steel, Mild Steel, and Galvanized Steel. Our diverse product portfolio includes pipes, tubes, flanges, pipe fittings, forged fittings, sheets, and plates. We are the most trusted name for supplying critical industrial applications with superior-quality steel products, built on reliability and excellent service. Our BS3606 Pipes are hard-wearing and high-performance-efficient. Jaxon Steel is here to fulfill all your Carbon Steel BS3606 Pipe requirements.
Carbon Steel BS3606 Pipes are extensively used for transporting gases and fluids in the oil and gas, chemical processing, and power generation sectors. Their high strength, durability, and resistance to corrosion make them perfect for applications like boiler tubes, heat exchangers, hydraulic systems, and automotive components. Additionally, these pipes are favored in infrastructure and mechanical construction due to their excellent weldability and cost-effectiveness. Their ability to perform under pressure and adapt to different working environments makes them a top choice for engineers and industrial designers around the globe.
Luke Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Houstan, USA.
