Luke Steel, a reputable manufacturer and supplier of Carbon Steel BS 6323 Pipes with headquarters in Houston, Houstan, provides dependable, superior steel tubing solutions for mechanical, automotive, and general engineering applications. These pipes, which are made in compliance with British Standard BS 6323, are intended for precise seamless or welded application in fluid systems and structural elements. Luke Steel guarantees that every pipe is manufactured in accordance with precise specifications, providing exceptional performance, weldability, and dimensional accuracy. Luke Steel is your go-to supplier for BS 6323 carbon steel pipes in a variety of industries because of its strong dedication to quality and client satisfaction.
Grades such as ERW1, ERW2, and ERW3 are used to make Carbon Steel BS 6323 Pipes. These pipes normally contain 0.10–0.20% carbon, 0.30–0.70% manganese, and trace amounts of silicon, phosphorus, and sulphur. These pipes have yield strengths of about 195–280 MPa and tensile strengths of 290–440 MPa. Excellent cold working characteristics and moderate strength are provided by BS 6323 pipes, which are renowned for their consistent wall thickness, toughness, and good formability. Depending on the needs of the application, they are typically supplied in normalised, cold-finished, or hot-finished conditions.
|
Grade |
Mfg. Process |
Chemical Composition(%) | ||||||||
|
C |
Si |
Mn |
P |
S |
Ni |
Cr |
Mo |
Others |
||
|
BW320 |
B |
0.16Max |
– |
0.30~0.70 |
0.040Max |
0.040Max |
– |
– |
– |
– |
|
ERW320 |
E |
0.16Max |
– |
0.30~0.70 |
0.040Max |
0.040Max |
– |
– |
– |
– |
|
ERW360 |
E |
0.17Max |
0.35Max |
0.40~0.80 |
0.040Max |
0.050Max |
– |
– |
– |
– |
|
ERW430 |
E |
0.21Max |
0.35Max |
0.40~1.20 |
0.040Max |
0.040Max |
– |
– |
– |
– |
|
S360 |
S |
0.17Max |
0.35Max |
0.40~0.80 |
0.040Max |
0.040Max |
– |
– |
– |
t 16mmMax 16mm<t 40mmMAX 40mm<t 65mmMax |
|
S430 |
S |
0.21Max |
0.35Max |
0.40~1.20 |
0.040Max |
0.040Max |
– |
– |
– |
t 16mmMax 16mm<t 40mmMAX 40mm<t 65mmMax |
|
SAW430 |
A |
0.25Max |
0.50Max |
1.20Max |
0.040Max |
0.040Max |
– |
– |
– |
t 16mmMax 16mm<t 40mmMAX 40mm<t 65mmMax |
Grade
| Tensile Test MPa or N/mm2 | Remaks (Similar to JIS) | Possibility Temperature | |
Min Yield point | Tensile Strength | |||
BW320 | 195 | 320~460 | – | |
ERW320 | 195 | 320~460 | – | |
ERW360 | 235 | 360~500 | (STPG370) | |
ERW430 | 195 | 430~570 | (STPG410) | |
S360 | 235 225 215 | 360~550 | (STPG310) | |
S430 | 275 265 255 | 430~570 | (STPG410) | |
SAW430 | 275 265 255 | 430~570 | (STPY400) | |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| Outer diameter and wall Thickness | |||||||||
|---|---|---|---|---|---|---|---|---|---|
| Execution | Size Range | OD Tolerance | Wall tolerance | ||||||
| Hot-rolled Tube | OD – 80 mmOD > 80 mmWall < 12 mmWall – 12 mm | ± 0.4 mm± 0.5 % of OD | ± 0.7 mm± (5 % x wallthickness + 0.1 mm | ||||||
| Hot-rolled peeled tube | All sizesWall < 12 mmWall – 12 mm | + 0.25/- 0 mm | ± 0.8 mm± (5 % x wall thickness+ 0.2 mm) | ||||||
| Cold Worked tubecold-rolled or cold-drawn | OD < 40 mmOD 40 – 80 mmOD > 80 Wall Thickness< 6 mm Wall Thickness6 – 8 mm Wall Thickness > 8 | + 0.30/- 0 mm*+ 0.35/- 0 mm*+ 0.40/- 0 mm* | ± 0.30 mm± 0.35 mm± 0.40 mm | ||||||
Jaxon Steel is a leading manufacturer and supplier of high-quality Carbon Steel BS6323 Pipe products in Houstan, USA. Specializing in steel solutions, we offer a wide range of products, including Carbon Steel, Alloy Steel, Mild Steel, and Galvanized Steel. Our product lineup includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets, and Plates. Known for our reliable delivery and exceptional customer service, we are committed to providing top-grade steel materials that ensure durability and performance across diverse industrial applications. Jaxon Steel is your trusted partner for all your Carbon Steel BS6323 Pipe needs.
In automotive engineering, carbon steel BS 6323 pipes are frequently used to fabricate exhaust tubes, hydraulic systems, fuel lines, and structural support elements. Because of their dependable dimensional tolerance and surface finish, these pipes are also used in general mechanical engineering for frames, rollers, and machinery parts. They are also used in fluid transport systems in homes and businesses where mechanical strength and moderate pressure are necessary. They are perfect for specialised applications in light structural work, fabrication shops, and vehicle manufacturing due to their ease of fabrication, bending, and welding.
Luke Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Houstan, USA.
