Luke Steel is a reputable and skilled manufacturer and supplier of Carbon Steel DIN 17173 Pipes with its headquarters located in Houston, USA. It provides strong and long-lasting piping solutions for a variety of industrial applications. These pipes, which are made in compliance with the German standard DIN 17173, are intended for use in high-temperature and high-pressure settings, specifically in boilers, heat exchangers, and similar systems. Luke Steel ensures exceptional performance, dependability, and longevity for both domestic and foreign industrial markets by meticulously manufacturing each pipe using premium raw materials and stringent quality control.
DIN 17173 Carbon Steel Heat-resistant steels like 15Mo3, which have trace amounts of silicon, sulphur, and phosphorus along with 0.12–0.20% carbon, 0.30–0.90% molybdenum, and 0.40–0.90% manganese, are commonly used to make pipes. These pipes have a yield strength of about 290 MPa and a tensile strength of 440–590 MPa. At high temperatures, DIN 17173 pipes are renowned for their good creep strength, oxidation resistance, and exceptional thermal stability. In order to guarantee performance under extended heat exposure, they are typically supplied in normalised or heat-treated conditions and are appropriate for welding.
| Element | Min | Max | Similar |
|---|---|---|---|
| Si | – | 0.3500 | – |
| S | – | 0.0250 | – |
| P | – | 0.0300 | – |
| Mn | 0.4000 | – | – |
| C | – | 0.1700 | – |
| Al | 0.0200 | – | – |
| Yield Rp0.2 (MPa) | Tensile Rm (MPa) | Impact KV/Ku (J) | Elongation A (%) | Reduction in cross section on fracture Z (%) | As-Heat-Treated Condition | Brinell hardness (HBW) |
|---|---|---|---|---|---|---|
| 435 (≥) | 197 (≥) | 42 | 43 | 14 | Solution and Aging, Annealing, Ausaging, Q+T,etc | 444 |
| Yield Strength | Tensile Strength | Elongation A5 min | |||
| MPa min | ksi min | MPa min | MPa min | ksi min | Percentage |
|  |  | 630 | – | – | 20 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Jaxon Steel is a leading manufacturer and supplier of high-quality Carbon Steel DIN 17173 Pipe products in Houstan, USA. Specializing in premium steel solutions, we offer a wide range of materials, including Carbon Steel, Alloy Steel, Mild Steel, and Galvanized Steel. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets, and Plates. With a strong reputation for reliable delivery and exceptional customer service, we are committed to providing top-grade steel materials that ensure durability and superior performance across various industrial applications. Jaxon Steel is your trusted partner for all Carbon Steel DIN 17173 Pipe requirements.
| Execution | Size Range | OD Tolerance | Wall tolerance |
|---|---|---|---|
| Hot-rolled Tube | OD – 80 mmOD > 80 mmWall < 12 mmWall – 12 mm | ± 0.4 mm± 0.5 % of OD | ± 0.7 mm± (5 % x wallthickness + 0.1 mm |
| Hot-rolled peeled tube | All sizesWall < 12 mmWall – 12 mm | #ERROR! | ± 0.8 mm± (5 % x wall thickness+ 0.2 mm) |
| Cold Worked tubecold-rolled or cold-drawn | OD < 40 mmOD 40 – 80 mmOD > 80 Wall Thickness < 6 mm Wall Thickness6 – 8 mm Wall Thickness > 8 | #ERROR! | ± 0.30 mm± 0.35 mm± 0.40 mm |
Carbon steel DIN 17173 pipes find extensive use in high-temperature settings, including boiler systems, chemical refineries, and power plants. They are perfect for applications where resistance to heat and oxidation is essential, such as pressure vessels, heat exchangers, superheater tubes, and steam pipelines, due to their heat-resistant qualities. The petrochemical industry also uses these pipes to move hot gases and fluids under pressure. DIN 17173 pipes offer long-lasting performance in demanding thermal environments due to their exceptional mechanical stability and weldability. They are crucial in energy production and processing facilities that function in hot environments because of their robustness and dependability.
Luke Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Houstan, USA.
