Luke Steel is a top-tier Carbon Steel EN 10084 Grade C16E Pipes manufacturer and supplier company located in Houston, USA. With its reputation for quality and innovation, Luke Steel provides high-performance steel solutions designed to address the different demands of industries across the country. The company has high precision engineering as its main focus and supplies C16E pipes that are highly machinable and with good case-hardening ability. Their products find extensive use in the mechanical, automotive, and industrial industries. Luke Steel‘s commitment to global standards and customer satisfaction establish them as a reliable supplier of long-lasting, dependable carbon steel products.
EN 10084 Grade C16E pipes contain 0.12–0.18% Carbon, 0.60–0.90% Manganese, and up to 0.40% Silicon, with Phosphorus and Sulfur limited to below 0.035%. This formula offers excellent machinability and case hardening suitability. Mechanically, the pipes provide a minimum yield point of 275 MPa and tensile strength from 650 to 880 MPa. The elongation is between 8% and 25%, which suggests that there is balanced ductility. At 100–155 HB Brinell hardness, the pipes function well under moderate stress and wear, particularly in heat-treated condition.
| Standard | AISI, DIN, EN, GB, IS, JIS, ASTM, ASME Pipe |
|---|---|
| Din En 10084 C16e Seamless Pipe Size | 4 to 219mm W. T.: 0.5 to 20mm |
| Bs EN 10084 Grade C10R Welded Pipe Size | 5.0 mm – 1219.2 mm |
| Din EN 10084 Grade C16E EFW Pipe size | 5.0 mm – 1219.2 mm |
| Norme En 10084 C15e Tube Swg & Bwg | 10 Swg., 12 Swg., 14 Swg., 16 Swg., 18 Swg., 20 Swg. |
| EN 10084 Grade C16R Pipe Schedule | SCH5, SCH10, SCH10S, SCH20, SCH30, SCH40, SCH40S, STD, SCH80, XS, SCH60, SCH80, SCH120, SCH140, SCH160, XXS |
| EN 10084 Grade 16MnCr5 Seamless Tube Size | 3.35 mm OD To 101.6 mm OD |
| Norme En 10084 C15e Welded Tube Size | 6.35 mm OD To 152 mm OD |
| En 10084 Steel Swg & Bwg | 10 Swg., 12 Swg., 14 Swg., 16 Swg., 18 Swg., 20 Swg. |
| En 10084 C10e Tube wall thickness | 0.020″ –0.220″, (special wall thicknesses available) |
| EN 10084 Grade C16R Carbon Steel Length | Single Random, Double Random, Standard & Cut length Pipe & Tube |
| Uni En Iso 10084 Finish | Polished, AP (Annealed & Pickled), BA (Bright & Annealed), MF |
| EN 10084 Grade 16MnCr5 Form | Round, Hydraulic, ‘U’ bent or Hollow,LSAW, Boiler, Straight Pipe, Clad Pipe, Rectangular, Square Pipe Etc |
| Bs EN 10084 Grade C10R Type | Welded, Seamless, ERW, EFW, Fabricated Pipe, ‘U’ bent or Hollow, Hydraulic, LSAW, Boiler, Straight Tube, Tube Coil, Round, Rectangular, Square Tube etc |
| Carbon | Silicon | Manganese | Phosphorous | Sulphur | Molybdenum | Nickel | Chromium | Copper | Others |
|---|---|---|---|---|---|---|---|---|---|
| 0.12-0.18 | max 0.40 | 0.60-0.90 | 0.035 | 0.035 | – | – | – | – | – |
| Yield Strength | Tensile Strength | Elongation A5 min | |||
|---|---|---|---|---|---|
| MPa min | ksi min | MPa min | MPa min | ksi min | Percentage |
| – | – | – | – | ||
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Jaxon Steel is a trusted manufacturer and supplier of high-quality Carbon Steel EN 10084 Grade C16E Pipe products in Houstan, USA. Specializing in premium steel materials, we offer a wide range of products, including Carbon Steel, Alloy Steel, Mild Steel, and Galvanized Steel. Our extensive inventory includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets, and Plates. With a commitment to reliable delivery and exceptional customer service, Jaxon Steel ensures top-grade materials for superior performance across various industrial applications. Trust Jaxon Steel for all your Carbon Steel EN 10084 Pipe needs.
| Temperature (°C) | Modulus of elasticity (GPa) | Mean coefficient of thermal expansion 10-6/(°C) between 20(°C) and | Thermal conductivity (W/m·°C) | Specific thermal capacity (J/kg·°C) | Specific electrical resistivity (Ω mm²/m) | Density (kg/dm³) | Poisson’s coefficient, ν |
|---|---|---|---|---|---|---|---|
| 43 | – | – | 0.14 | – | |||
| 259 | 363 | – | 44.3 | 331 | – | ||
| 197 | – | 43 | 13.2 | 142 | 124 |
EN 10084 Grade C16E Luke Steel pipes find extensive use in applications demanding high surface hardness and moderate wear resistance. Typical applications are shafts, axles, gears, spindles, and mechanical linkages in general machinery and automobiles. Their good machinability facilitates accurate manufacture, while their case-hardening nature provides increased surface durability without affecting core toughness. These properties make the pipes suitable for components under friction, impact, and cyclic load. Whether in industrial equipment or transmission systems, C16E pipes provide a consistent solution that satisfies the performance requirements of a wide range of engineering applications across both mechanical and structural fields.
Luke Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Houstan, USA.
