Luke Steel from Houston, USA is a reliable Carbon Steel EN 10216-3 Pipes manufacturer and supplier renowned for providing high-quality products to numerous industries. With emphasis on precision engineering and rigorous attention to international standards, Luke Steel guarantees longevity, strength, and performance in each pipe. Our state-of-the-art manufacturing units and skilled employees allow us to fulfill bulk orders with quick delivery and reasonable costs. Dedicated to excellence, Luke Steel has developed a good reputation for dependability, quality control, and outstanding customer support in domestic as well as international markets.
Carbon Steel EN 10216-3 Pipe largely comprises iron with controlled levels of carbon, manganese, silicon, and minor elements. These pipes have good mechanical properties such as high tensile strength, good yield strength, and consistent elongation abilities. They are normalized rolled or normalized to provide enhanced toughness and ductility. Their composition and heat treatment ensure that the pipe is resistant to stress, impact, and pressure. These features allow them to be used in high-pressure and high-temperature applications, particularly in mechanical and structural systems. The strength-to-flexibility ratio sustains their application under rigorous operational conditions.
| Steel Grade | Steel No. | C max. | Si max. | Mn | P max. | S max. | Cr max. | Mo max. | Ni max. | Al max. | Cu max. | N max. | Nb max. | Ti max. | V max. | Nb+Ti+V max. |
| P275NL1 | 1.0488 | 0,16 | 0,40 | 0,50 to 1,50 | 0,025 | 0,02 | 0,30 | 0,08 | 0,50 | 0,02 | 0,30 | 0,02 | 0,05 | 0,04 | 0,05 | 0,05 |
| P275NL2 | 1.1104 | 0,16 | 0,40 | 0,50 to 1,50 | 0,025 | 0,015 | 0,30 | 0,08 | 0,50 | 0,02 | 0,30 | 0,02 | 0,05 | 0,04 | 0,05 | 0,05 |
| Yield Strength | Tensile Strength | Elongation A5 min | |||
|---|---|---|---|---|---|
| MPa min | ksi min | MPa min | MPa min | ksi min | Percentage |
| 490 | 650 | – | 22 | ||
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Jaxon Steel is a trusted manufacturer and supplier of high-quality Carbon Steel EN 10216-3 Pipe products in Houstan, USA. Specializing in premium steel materials, we offer a diverse range of products, including Carbon Steel, Alloy Steel, Mild Steel, and Galvanized Steel. Our extensive inventory includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets, and Plates. With a strong commitment to timely delivery and exceptional customer service, Jaxon Steel provides top-grade materials that deliver exceptional performance across various industrial applications. Trust Jaxon Steel for all your Carbon Steel EN 10216-3 Pipe requirements.
| 1/8″ IPS(.405″ O.D.) | 3 1/2″ IPS( 4.000″ O.D.) |
|---|---|
| SCH 40, 80 | SCH 10, 40, 80, 160, XXH |
| 1/4″ IPS(.540″ O.D.) | 4″ IPS(4.500″ O.D.) |
| SCH 10, 40, 80 | SCH 10, 40, 80, 160, XXH |
| 3/8″ IPS(.675″ O.D.) | 5″ IPS( 5.563″ O.D.) |
| SCH 10, 40, 80 | SCH 10, 40, 80, 160, XXH |
| 1/2″ IPS(.840″ O.D.) | 6″ IPS(6.625″ O.D.) |
| SCH 5, 10, 40, 80, 160, XXH | SCH 5, 10, 40, 80, 120, 160, XXH |
| 3/4″ IPS(1.050″ O.D.) | 8 ” IPS(8.625″ O.D.) |
| SCH 10, 40, 80, 160, XXH | SCH 5, 10, 40, 80, 120, 160, XXH |
| 1″ IPS:(1.315′ O.D.) | 10″ IPS(10.750″ O.D.) |
| SCH 5, 10, 40, 80, 160, XXH | SCH 10, 20, 40, 80 (.500), TRUE 80(.500) |
| 1-1/4″ IPS(1.660″ O.D.) | 12″ IPS(12.750″ O.D.) |
| SCH 10, 40, 80, 160, XXH | SCH 10, 20, 40(.375), TRUE40(.406), SCH80(.500) |
| 1-1/2″ IPS(1.900″ O.D.) | 14″ IPS(14.000″ O.D.) |
| SCH 10, 40, 80, 160, XXH | SCH10 (.188), SCH40 (.375) |
| 2″ IPS(2.375″ O.D.) | 16″ IPS(16.000″ O.D.) |
| SCH 10, 40, 80, 160, XXH | SCH10(.188), SCH40(.375) |
| 2 1/2″ IPS(2.875″ O.D.) | 18″ IPS (18.000″ O.D.) |
| SCH 10, 40, 80, 160, XXH | SCH-40 (.375) |
| 3″ IPS( 3.500″ O.D.) | |
| SCH 5, 10, 40, 80, 160, XXH |
| Execution | Size Range | OD Tolerance | Wall tolerance |
|---|---|---|---|
| Hot-rolled Tube | OD – 80 mmOD > 80 mmWall < 12 mmWall – 12 mm | ± 0.4 mm± 0.5 % of OD | ± 0.7 mm± (5 % x wallthickness + 0.1 mm |
| Hot-rolled peeled tube | All sizesWall < 12 mmWall – 12 mm | + 0.25/- 0 mm | ± 0.8 mm± (5 % x wall thickness+ 0.2 mm) |
| Cold Worked tubecold-rolled or cold-drawn | OD < 40 mmOD 40 – 80 mmOD > 80 Wall Thickness< 6 mm Wall Thickness6 – 8 mm Wall Thickness > 8 | + 0.30/- 0 mm*+ 0.35/- 0 mm*+ 0.40/- 0 mm* | ± 0.30 mm± 0.35 mm± 0.40 mm |
EN 10216-3 Carbon Steel Pipes are extensively applied in various industries because of their superior strength, toughness, and high-pressure as well as high-temperature resistance. Some typical applications include power plants, petrochemical plants, oil and gas piping, boilers, and heat exchangers. They also find application in construction, mechanical equipment, and general engineering applications. Their robustness makes them perfect for conveying fluids and gases in critical applications. The pipes are particularly sought after for their cost-performance, functioning under tough conditions to provide long-lasting service with low maintenance in industrial as well as structural applications.
Luke Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Houstan, USA.
