Luke Steel, located in Houston, Houstan, has earned a solid reputation as a reliable manufacturer and supplier of top-notch Carbon Steel EN 10305-4 Pipes. These pipes are designed to meet the rigorous demands of hydraulic and pneumatic applications. With a keen emphasis on precision and performance, Luke Steel delivers cold-drawn, seamless pipes that adhere to international standards and cater to specific client needs. Renowned for their consistent wall thickness, dimensional accuracy, and exceptional surface finish, these pipes are perfect for high-pressure systems. Luke Steel’s dedication to quality, prompt delivery, and competitive pricing has made it a go-to partner for various industrial sectors both in the United States and around the world.
The Carbon Steel EN 10305-4 Pipes are primarily made from low carbon content (usually around 0.16–0.20% C), along with carefully controlled amounts of manganese, phosphorus, and sulfur. These pipes boast excellent cold-forming capabilities, good weldability, and reliable mechanical performance. In terms of mechanics, they provide a tensile strength between 490–630 MPa, yield strength starting from 340 MPa, and an elongation of about 22%, depending on their size and treatment. The cold-drawn precision process enhances their dimensional tolerance, smooth surface finish, and structural uniformity—key features for high-pressure hydraulic systems.
| Steel grade | % of mass | |||||
| Symbol | C max. | Si max. | Mn max. | P max | S max | Al total. Max |
| E215 | 0,10 | 0,05 | 0,70 | 0,025 | 0,015 | 0,025 |
| E235 | 0,17 | 0,35 | 1,20 | 0,025 | 0,015 | – |
| E355 | 0,22 | 0,55 | 1,60 | 0,025 | 0,015 | – |
| Steel grade | Yield limit ReH Min. MPa | Tensile strength Rm Min MPa | Elongation A Min % |
| Symbol | |||
| E215 | 215 | 290 to 430 | 30 |
| E235 | 235 | 235 to 480 | 25 |
| E355 | 355 | 490 to 630 | 22 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Jaxon Steel is a trusted manufacturer and supplier of high-quality Carbon Steel EN 10305-4 Pipe products in Houstan, USA. Specializing in premium steel materials, we offer a diverse range of products, including Carbon Steel, Alloy Steel, Mild Steel, and Galvanized Steel. Our extensive inventory features Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets, and Plates. With a strong commitment to timely delivery and exceptional customer service, Jaxon Steel ensures the supply of top-grade materials that deliver superior performance in various industrial applications. Trust Jaxon Steel for all your Carbon Steel EN 10305-4 Pipe needs.
| 1/8″ IPS(.405″ O.D.) | 3 1/2″ IPS( 4.000″ O.D.) |
|---|---|
| SCH 40, 80 | SCH 10, 40, 80, 160, XXH |
| 1/4″ IPS(.540″ O.D.) | 4″ IPS(4.500″ O.D.) |
| SCH 10, 40, 80 | SCH 10, 40, 80, 160, XXH |
| 3/8″ IPS(.675″ O.D.) | 5″ IPS( 5.563″ O.D.) |
| SCH 10, 40, 80 | SCH 10, 40, 80, 160, XXH |
| 1/2″ IPS(.840″ O.D.) | 6″ IPS(6.625″ O.D.) |
| SCH 5, 10, 40, 80, 160, XXH | SCH 5, 10, 40, 80, 120, 160, XXH |
| 3/4″ IPS(1.050″ O.D.) | 8 ” IPS(8.625″ O.D.) |
| SCH 10, 40, 80, 160, XXH | SCH 5, 10, 40, 80, 120, 160, XXH |
| 1″ IPS:(1.315′ O.D.) | 10″ IPS(10.750″ O.D.) |
| SCH 5, 10, 40, 80, 160, XXH | SCH 10, 20, 40, 80 (.500), TRUE 80(.500) |
| 1-1/4″ IPS(1.660″ O.D.) | 12″ IPS(12.750″ O.D.) |
| SCH 10, 40, 80, 160, XXH | SCH 10, 20, 40(.375), TRUE40(.406), SCH80(.500) |
| 1-1/2″ IPS(1.900″ O.D.) | 14″ IPS(14.000″ O.D.) |
| SCH 10, 40, 80, 160, XXH | SCH10 (.188), SCH40 (.375) |
| 2″ IPS(2.375″ O.D.) | 16″ IPS(16.000″ O.D.) |
| SCH 10, 40, 80, 160, XXH | SCH10(.188), SCH40(.375) |
| 2 1/2″ IPS(2.875″ O.D.) | 18″ IPS (18.000″ O.D.) |
| SCH 10, 40, 80, 160, XXH | SCH-40 (.375) |
| 3″ IPS( 3.500″ O.D.) | |
| SCH 5, 10, 40, 80, 160, XXH |
You’ll find Carbon Steel EN 10305-4 Pipes widely utilized in hydraulic and pneumatic systems across vehicles, machinery, and industrial automation. Their precision manufacturing makes them ideal for high-pressure fuel lines, brake systems, and fluid power applications. They’re also commonly found in construction machinery, agricultural equipment, and manufacturing tools where reliability and dimensional accuracy are paramount. Thanks to their excellent formability and weldability, these pipes can be tailored for custom-engineered systems that require bending or flaring. Plus, their corrosion resistance can be further enhanced with coatings, making them a durable choice for challenging environments.
