Luke Steel, a reputable manufacturer and supplier of Carbon Steel EN-44 Bars with headquarters in Houston, Houstan, offers high-end steel products for a range of industrial uses. High-carbon alloy steel EN-44 is renowned for its remarkable tensile strength, wear resistance, and hardness following heat treatment. Luke Steel makes sure every EN-44 bar satisfies stringent industry standards by combining sophisticated manufacturing processes with stringent quality control. Luke Steel is dedicated to providing EN-44 steel bars with exceptional mechanical performance and consistent quality, catering to the heavy engineering, tool manufacturing, and automotive industries.
The typical composition of Carbon Steel EN-44 Bars is 0.40–0.48% carbon, 0.80–1.10% chromium, 0.70–1.00% manganese, and trace amounts of silicon and molybdenum. After quenching and tempering, this alloy steel has exceptional hardness and a high tensile strength between 850 and 1100 MPa. EN-44 is appropriate for heavy-duty applications due to its good fatigue strength, toughness, and wear resistance. Superior dimensional stability and resistance to mechanical stress are made possible by its exceptional hardenability, which enables a robust surface and a resilient core.
| Grade | EN44 |
|---|---|
| Specification | BS970 1.0904 55Si7 55S6 55Si2Mn ASTM 9255 |
| Round bar size | Diameter: 3-~800mm |
| Hex Bar size | 2-100mm A/F |
| Flat bar size | Thickness: 2 -100mm |
| Width: 10 to 500mm | |
| Square bar size | 4 to 100mm |
| Angle bar size | 3mm*20mm*20mm~12mm*100mm*100mm |
| Section | 3.0 to 12.0mm thickness |
| Channel Bar | 80 x 40mm to 150 x 75mm section; 5.0 to 6.0mm thickness |
| Hollow Bar | 32mm OD x 16mm ID to 250mm OD x 200mm ID) |
| Billet Size | 1/2″ to 495mm Diameter |
| Rectangles Size | 33 x 30mm to 295 x 1066mm |
| Finish | Cold (bright) drawn, centreless ground,smooth turned, peeled, slit rolled edge, hot rolled, hot rolled annealed, Rough Turned, Bright, Polish, Grinding, Centreless Ground & Black |
| Tolerance | H8, H9, H10, H11, H12, H13K9, K10, K11, K12 or as per clients’ requirements |
| Surface | Bright, Hot Rolled Pickled, Cold Drawn, Sand Blasting Finished, Polished, Hairline |
| Condition | Hardened & tempered, annealed |
| Technique | EN45 Hot Rolled, Cold Drawn, Cold Rolled, Forged Round Bar, Rod |
| Processing | Bar cutting to 650mm |
| Form | EN45 Welding Rod, Round, Rod, T-Bar, Channel Bar, Precision Ground Bar, Flat Bar, Square, Blocks, Round Rod, Rings, Hollow, Triangle, Rectangle, Hex (A/F), Threaded, Half Round Bar, Profiles, Billet, Ingot, I/H Bar, Forging etc. |
| Element | En42J |
| C | 0.75 – 0.90% |
| Mn | 0.50 – 0.90% |
| Si | 0/1 – 0.35 |
| S | 0.04% Max |
| P | 0.04% Max |
|
ULTIMATE TENSILE STRENGTH, S. (MPA) |
621 |
|---|---|
|
Modulus of elasticity, E (Gpa) |
204 |
|
Fatigue strength coefficient, of (Mpa) |
948 |
|
Fatigue strength exponent, b |
-0.092 |
|
Fatigue ductility coeffient ,ef |
0.26 |
|
Fatigue ductility exponent,c |
-0.445 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Type | SIZES (mm) | SIZES (Inches) | ISO Tolerance |
|---|---|---|---|
Cold Drawn and Polish | 3.00 – 75.00 | 1/8″ – 3.00″ | h8-h9-h10-h11 |
Cold Drawn and Ground | 10.00 – 75.00 | 5/6″ – 2.50″ | h8-h9-h10-h11 |
Peeled and Polished | 40.00 – 150.00 | 1.50″ – 6.00″ | h11, h11-DIN 1013 |
Peeled and Ground | 20.00 – 50.00 | 3/4″ – 2.00″ | h9-h10-h11 |
Cut to size on request (tolerance +2/-0 mm). Standard lengths of EN45 Bars 2000 mm up to 6000 mm available
5.0 | 45.0 |
6.0 | 50.0 |
7.0 | 55.0 |
8.0 | 60.0 |
9.0 | 65.0 |
10.0 | 70.0 |
12.0 | 75.0 |
16.0 | 80.0 |
20.0 | 90.0 |
25.0 | 100.0 |
30.0 | 130.0 |
35.0 | 160.0 |
40.0 | 200.0 |
Applications needing high strength, hardness, and wear resistance frequently use carbon steel EN-44 bars. Common applications include the production of machine tool parts, crankshafts, shafts, heavy-duty gears, and automotive parts that are exposed to high levels of stress and friction. In forging applications where strength and durability are essential, EN-44 is also preferred. It is perfect for industrial machinery components, high-strength fasteners, and gearbox parts due to its exceptional mechanical qualities and fatigue resistance. EN-44 steel bars are a popular material for parts that operate in demanding environments because of their exceptional hardness and toughness combination.
