Luke Steel is a well-known manufacturer and supplier located in Houston, Houstan, focusing on high-quality Carbon Steel EN Series Channels. With a strong dedication to precision engineering and durability, Luke Steel offers a diverse selection of EN Series Channels designed to meet the structural and fabrication demands of various industries. Supported by advanced technology and a talented workforce, the company guarantees products that adhere to international standards for strength, corrosion resistance, and dimensional accuracy. Luke Steel has built a solid reputation for delivering reliable steel solutions to clients in the construction, automotive, and manufacturing sectors.
Carbon Steel EN Series Channels are primarily made up of carbon and iron, with different amounts of manganese, phosphorus, and sulfur depending on the specific EN grade, such as EN8, EN9, or EN19. These steels are known for their excellent tensile strength, high hardness, and outstanding machinability. Their mechanical properties include good ductility, improved wear resistance, and the capability to withstand stress and impact. The balanced chemical composition of these steels makes them perfect for structural applications where toughness and durability are crucial.
| Specifications | : | ASTM |
| Dimensions | : | EN, DIN, JIS, ASTM, BS, ASME, AISI |
| Carbon Steel En Series Angle | : | 5mm to 9mm |
| Carbon Steel En Series Channel | : | 40mm*20mm~300mm*300mm |
| Carbon Steel En Series Beam | : | 3″ thru 12.31″ |
| Carbon Steel En Series Chain | : | 1/8 inch – 1/2 inch Diameter |
| Thickness | : | 3.0mm – 120mm |
| Length | : | 3MTR, 4MTR, 5MTR, 6MTR, or Custom Cut Sizes |
| Type | : | Angle, C Channel, U Channel, H Beam, I Beam, T Beam, W Beam, Chain |
| Grade | ||||||
| C% | Si% | Mn% | Cr% | Mo% | W% | |
| EN-1A | 0.007 TO 0.15 | 0.10 | 0.80 TO 1.00 | S | P | – |
| 0.20 TO 0.30 | 0.70 MAX | |||||
| EN-8 | 0.35 TO 0.45 | 0.05 TO 0.30 | 0.60 TO 1.00 | S | P | – |
| 0.06 MAX | 0.06 MAX | |||||
| EN-9 | 0.50 TO 0.60 | 0.05 TO 0.30 | 0.5 TO 0.80 | – | – | – |
| EN-19(V 320) | 0.35 TO 0.45 | 0.10 TO 0.30 | 0.5 TO 0.80 | 0.90 TO 1.40 | 0.20 TO 0.40 | |
| EN-24(V 130) | 0.35 TO 0.45 | 0.10 TO 0.35 | 0.45 TO 0.70 | 0.90 TO 1.40 | 0.20 TO 0.35 | NI |
| 1.3 TO 1.8 | ||||||
| EN-31 R-100 | 0.90 TO 1.20 | 0.10 TO 0.35 | 0.30 TO 0.75 | 1.00 TO 1.60 | – | – |
| EN-36C E-200 | 0.12 TO 0.18 | 0.10 TO 0.35 | 0.30 TO 0.60 | 0.60 TO 1.10 | – | NI |
| 3.0 TO 3.75 | ||||||
| EN-42 | 0.70 TO 0.85 | 0.10 TO 0.40 | 0.55 TO 0.75 | – | – | – |
| EN-44 | 0.90 TO 1.20 | 0.30 | 0.45 TO 0.70 | – | – | – |
| EN-45 F-110 | 50 TO 0.60 | 1.5 TO 2.0 | 0.70 TO 1.00 | – | – | – |
| EN-351 | 0.10 TO 0.20 | 0.35 | 0.60 TO 1.00 | 0.40 to 0.80 | 0.08 to 0.10 | NI |
| 0.60 TO 1.00 | ||||||
| EN-353 | 0.10 TO 0.20 | 0.35 | 0.50 TO 1.00 | 0.75 TO 1.25 | 0.08 to o.15 | NI |
| 1.00 TO 1.50 |
| Grade | HEAT TREATMENT | CORRESPONDING SPECIFICATION | |||||
| Hardening Temperature | Quenching Medium | Tempering Temperature | Brinell Rock well hardness | JAPAN JIS | AISI | POLDI THREAD | |
| EN-1A | – | – | – | – | – | – | – |
| EN-8 | 750-900 | OIL | 150-200 | ||||
| EN-9 | 850-900 | OIL | 200-250 | 55-60 | |||
| EN-19 (V 320) | 900-950 | OIL | 200-225 | 45-55 | SCM 4 | 4140 | |
| EN-24 (V 130) | 830-860 | OIL | 540-680 | 45-55 | SNCM 8 | 4340 | |
| EN-31 R-100 | 820-860 | OIL | 180-225 | 59-65 | |||
| EN-36C E-200 | 780-860 | OIL | 170-210 | 61-63 | SNC 22 | 3415 | |
| EN-42 | 600-700 | DIRECT HARDENING | 40-45 | ||||
| EN-44 | 650-750 | OIL | 150 | 45-50 | |||
| EN-45 | 830-860 | OIL | 470-520 | 50-55 | 9255 | ||
| EN-351 | 850-860 | OIL | 175-200 | 62-64 | |||
| EN-353 | 840-870 | OIL | 150-200 | 62-64 | |||
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Carbon Steel EN Series Channel is a trusted manufacturer and supplier of high-quality EN Series Carbon Steel Channels in Houstan, USA. We specialize in premium steel products, with a focus on EN Series Carbon Steel, known for its excellent strength, durability, and versatility across various industrial applications. Our extensive inventory also includes Pipes, Tubes, Flanges, Forged Fittings, and Bars to meet diverse industry needs. Committed to fast delivery and outstanding customer service, we use only the finest raw materials to ensure superior performance and reliability. Contact us today for all your EN Series Carbon Steel Channel requirements!
In the construction industry, Carbon Steel EN Series Channels are commonly used in structural frameworks, support systems, and load-bearing assemblies. They also play a vital role in manufacturing machinery parts, automotive frames, and equipment support structures. Their high strength and formability make them ideal for railways, shipbuilding, and heavy industrial applications. These channels are preferred for their durability, ease of fabrication, and ability to maintain structural integrity even in tough environments and under heavy operational loads.
