Luke Steel, a prominent manufacturer and supplier based in Houston, Houstan, stands out as a top provider of Carbon Steel F56 forged fittings. These fittings are celebrated for their remarkable strength, reliability, and precision engineering. Crafted to adhere to stringent industry standards, they are specifically designed for high-pressure and high-stress applications across a variety of sectors. Luke Steel prides itself on delivering durable, high-performance products, complemented by efficient service and timely delivery, making them a go-to partner for clients seeking robust piping components.
The Carbon Steel F56 forged fittings are primarily made of iron, featuring a moderate carbon content along with trace amounts of alloying elements that enhance their strength and durability. Typically, these fittings boast a minimum yield strength of 390 MPa and a tensile strength that ranges from 485 to 625 MPa. Their impressive mechanical properties, including excellent toughness and impact resistance, are further enhanced through the forging process, ensuring they perform reliably in demanding environments.
Standard : ASTM A694 / ASME SA 694
Dimensions : ASME/ANSI 16.11, MSS SP-79, 83, 95, 97, BS 3799
Size : 1/8″ NB to 4″ NB
Type : Socketweld Fittings, Screwed-Threaded Fittings (NPT or PT Type)
Rating Pressure : Threaded End – 2000 /3000/ 6000 LBS. Socket-weld End – 3000 / 6000/ 9000 LBS.
| Grade | C | Si | Mn | P | S | Mo | Ni | Cr | Cu | V | Nb |
| F56 | 0.17-0.23 | 0.15-0.40 | 1.30-1.60 | ≤ 0.025 | ≤ 0.015 | 0.45-0.65 | ≤ 0.30 | ≤ 0.30 | ≤ 0.25 | – | 0.025~0.050 |
| Grade | Yield Strength, Min (KSI ) | Tensile Strength, Min (KSI) |
| A694 | 65 | 77 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| ASME B16.11 | Factory-Made Wrought Socketweld Fittings | CS F56 Forged Screwed Elbows, Street Elbow, Carbon Steel F56 Screwed Unequal Tee, Steel Straight Tee, Carbon Steel F56 Reducing Coupling, Carbon Steel F56 Hex Plug, Forged Straight Tees, Socket Weld Pipe Cap, Forged Pipe Cap, Equal Crossess, CS F56 Threaded Bushing, Carbon Steel F56 Screwed Caps, Swedge Nipples |
| MSS-SP-79 | standard Practice covers ratings, tolerances, finish, dimensions, marking and material requirements for socket-welding | Carbon Steel F56 Barrel Nipples, CS F56 Forged Threaded Boss, Carbon Steel F56 Forged Hex Head Bull Plugs |
| MSS-SP-83 | Forged and Fabricated Socket-Welding Fittings for Low Pressure, Corrosion Resistant Applications | Carbon Steel F56 High Quality Socket weld 90° Elbow, Straight and Reducing-on-the-Tees, Forged 45° Short Radius Elbow, CS F56 caps, 3000LB Socket Weld Cross |
| MSS-SP-95 | Integrally Reinforced Forged Fittings – Socket Welding, Threaded, and Buttwelding Ends | CS F56 Socket weld Long Radius 90 Degree Elbows, Reducing Nipple, Socket weld Bushing, Threaded Plug, End Pipe caps, Carbon Steel F56 Coupling |
These fittings find extensive use in industries such as oil and gas, petrochemical, power generation, and shipbuilding. Perfect for connecting pipes and equipment in high-pressure systems, they come in various forms, including elbows, tees, couplings, and unions. Their strength, resistance to corrosion, and ability to create tight seals make them ideal for transporting fluids and gases, ensuring safe and efficient operation of systems. These fittings play a crucial role in maintaining the integrity and performance of essential infrastructure over long periods.
Luke Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Houstan, USA.
