Luke Steel, based in Houston, Houstan, and formed in 1995, is a renowned producer and supplier of high–quality carbon steel JIS G3458 tubing. Having a rich history of accuracy engineering and focus on quality, the organization services many industry segments in need of reliable and thermal-resistant tubing products. Experts in seamless alloy steel tubes, Luke Steel manufactures products designed to withstand the exacting conditions of high-temperature applications like power plants, refineries, and chemical processing facilities. Based on a broad distribution network and a firm customer-centric orientation, Luke Steel continues to establish industry standards for reliability, performance, and compliance with global standards.
Carbon steel JIS G3458 tubes consist mainly of carbon (0.20% maximum) and manganese (0.30%–0.80%), with lesser amounts of phosphorus and sulfur (below 0.035%) to facilitate weldability and reduce brittleness. Silicon, chromium, and molybdenum are added to provide resistance to heat. These tubes provide remarkable mechanical performance with tensile strengths of about 380 MPa, yield strengths of 205 MPa, and elongation rates of up to 30%, varying with grade. Their combination of mechanical properties and alloy content positions them for applications involving high stress and high temperatures.
| Standards | JIS G3458 Carbon Steel Pipe |
|---|---|
| JIS G3456 Carbon Steel Seamless Pipe Size | 4 to 219mm W. T.: 0.5 to 20mm |
| JIS G3456 Carbon Steel Welded Pipe Size | 5.0 mm – 1219.2 mm |
| JIS G3456 Carbon Steel EFW Pipe size | 5.0 mm – 1219.2 mm |
| JIS G3456 Carbon Steel Tube Swg & Bwg | 10 Swg., 12 Swg., 14 Swg., 16 Swg., 18 Swg., 20 Swg. |
| JIS G3456 Carbon Steel Pipe Schedule | SCH5, SCH10, SCH10S, SCH20, SCH30, SCH40, SCH40S, STD, SCH80, XS, SCH60, SCH80, SCH120, SCH140, SCH160, XXS |
| JIS G3456 Carbon Steel Seamless Tube Size | 3.35 mm OD To 101.6 mm OD |
| JIS G3456 Carbon Steel Welded Tube Size | 6.35 mm OD To 152 mm OD |
| Swg & Bwg | 10 Swg., 12 Swg., 14 Swg., 16 Swg., 18 Swg., 20 Swg. |
| JIS G3456 Carbon Steel Tube wall thickness | 0.020″ –0.220″, (special wall thicknesses available) |
| Length | Single Random, Double Random, Standard & Cut length Pipe & Tube |
| Finish | Polished, AP (Annealed & Pickled), BA (Bright & Annealed), MF |
| Form | Round, Hydraulic, ‘U’ bent or Hollow,LSAW, Boiler, Straight Pipe, Clad Pipe, Rectangular, Square Pipe Etc |
| Type | Welded, Seamless, ERW, EFW, Fabricated Pipe, ‘U’ bent or Hollow, Hydraulic, LSAW, Boiler, Straight Tube, Tube Coil, Round, Rectangular, Square Tube etc |
| End | Plain End, Beveled End, Treaded Pipe & Tube |
| Marking | All JIS G3456 Carbon Steel Pipe are marked as follows: Standard, Grade, OD, Thickness, Length, Heat No. (Or according to the customer’s request.) |
| Application | Oil Pipe & Tube, Gas Pipe & Tube, Fluid Pipe & Tube, Boiler Pipe & Tube, Heat exchanger Tube |
| Value Added Service | Draw & Expansion as per required Size & Length, Polish (Electro & Commercial) Annealed & Pickled Bending, Machining Etc. |
| Test Certificate | Manufacturer Test Certificate Laboratory Test Certificate from Govt. Approved Lab. Under Third Party Inspection |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Jaxon Steel is a prime manufacturer and distributor of high-class Carbon Steel JIS G3458 Pipe in Houstan, USA. Offering top-grade steel materials, the company provides its customers with extensive products such as Carbon Steel, Alloy Steel, Mild Steel, and Galvanized Steel. A wide variety of products in stock includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets, and Plates. We strive for timely delivery and exceptional service to our valued customers. Only the best of raw materials comes into play here to ensure highest performance in all industrial applications with demanding requirements. Contact us now to fulfill your Carbon Steel JIS G3458 Pipe requirement.
| Type | Allowable Deviation of Outer Diameter | Allowable Deviation of Wall Thickness | |||
| Hot-Working Seamless Steel Pipe | ＜50 mm | ± 0.5 mm | ＜ 4 mm ≥ 4mm | ± 0.5 mm ±12.5% | ≤ 20% of thickness |
| ≥ 50mm~＜160mm | ± 1% | ||||
| ≥ 160mm~≤ 200 mm | ± 1.6 mm | ||||
| ≥ 200 mm | ± 0.8% | ||||
| For ≥350 mm ones, we can measure according to the perimeters. Allowable deviation is ± 0.5%. | |||||
| Cold-Working Steel Seamless Pipe and Electric-Resistance Welded(ERW) Steel Pipe | ≤ 40 mm | ± 0.03 mm | ＜ 2 mm ≥ 2 mm | ± 0.2 mm ± 10 | |
Carbon steel JIS G3458 pipes have extensive applications in many industries due to their superior strength, durability, and thermal conductivity. In power generation, they are crucial in the construction of boilers, superheaters, and economizers to provide an efficient heat exchange. Due to their high-temperature and pressure resistance, they are also perfect to use in fossil fuel plants and steam pipelines. In the petrochemical and oil refinery industries, these pipes provide reliable performance in harsh and corrosive environments. In addition, their flexibility and durability make them a favorite when it comes to process piping in petrochemical plants as well as high-performance mechanical systems for industrial applications.
Luke Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Houstan, USA.
