Established in 1995 with headquarters in Houstan, Houstan, Luke Steel is a prominent producer and supplier of superior quality carbon steel JIS G3455 pipes. These seamless alloy steel tubes are specially designed to deliver top performance in high-temperature devices like boilers, heat exchangers, and superheaters. Dedicated to maintaining international standards, Luke Steel assures each pipe provides long-term dependability, toughness, and efficiency. With a strong distribution network and a well-deserved image for technical proficiency, Luke Steel is an established partner to numerous industries, producing precision-stamped steel products designed to be compliant with the demanding needs of mechanical and thermal systems.
JIS G3455 carbon steel tubes mainly consist of carbon (≤0.25%), manganese (0.30–1.10%), and trace elements of phosphorus and sulfur (≤0.035%), with added elements like silicon, chromium, and molybdenum to improve mechanical properties. These pipes have tensile strength of about 370 MPa, yield strength of about 216 MPa, and elongation of 30% based on grade. They have good weldability, formability, and thermal stress resistance due to their balanced chemistry, thus being most suitable for high-temperature and high-pressure applications in industrial processes.
| Standards | JIS G3462 Carbon Steel Pipe |
|---|---|
| JIS G3461 Carbon Steel Seamless Pipe Size | 4 to 219mm W. T.: 0.5 to 20mm |
| JIS G3461 Carbon Steel Welded Pipe Size | 5.0 mm – 1219.2 mm |
| JIS G3461 Carbon Steel EFW Pipe size | 5.0 mm – 1219.2 mm |
| JIS G3461 Carbon Steel Tube Swg & Bwg | 10 Swg., 12 Swg., 14 Swg., 16 Swg., 18 Swg., 20 Swg. |
| JIS G3461 Carbon Steel Pipe Schedule | SCH5, SCH10, SCH10S, SCH20, SCH30, SCH40, SCH40S, STD, SCH80, XS, SCH60, SCH80, SCH120, SCH140, SCH160, XXS |
| JIS G3461 Carbon Steel Seamless Tube Size | 3.35 mm OD To 101.6 mm OD |
| JIS G3461 Carbon Steel Welded Tube Size | 6.35 mm OD To 152 mm OD |
| Swg & Bwg | 10 Swg., 12 Swg., 14 Swg., 16 Swg., 18 Swg., 20 Swg. |
| JIS G3456 Carbon Steel Tube wall thickness | 0.020″ –0.220″, (special wall thicknesses available) |
| Length | Single Random, Double Random, Standard & Cut length Pipe & Tube |
| Finish | Polished, AP (Annealed & Pickled), BA (Bright & Annealed), MF |
| Form | Round, Hydraulic, ‘U’ bent or Hollow,LSAW, Boiler, Straight Pipe, Clad Pipe, Rectangular, Square Pipe Etc |
| Type | Welded, Seamless, ERW, EFW, Fabricated Pipe, ‘U’ bent or Hollow, Hydraulic, LSAW, Boiler, Straight Tube, Tube Coil, Round, Rectangular, Square Tube etc |
| End | Plain End, Beveled End, Treaded Pipe & Tube |
| Marking | All JIS G3461 Carbon Steel Pipe are marked as follows: Standard, Grade, OD, Thickness, Length, Heat No. (Or according to the customer’s request.) |
| Application | Oil Pipe & Tube, Gas Pipe & Tube, Fluid Pipe & Tube, Boiler Pipe & Tube, Heat exchanger Tube |
| Value Added Service | Draw & Expansion as per required Size & Length, Polish (Electro & Commercial) Annealed & Pickled Bending, Machining Etc. |
| Test Certificate | Manufacturer Test Certificate Laboratory Test Certificate from Govt. Approved Lab. Under Third Party Inspection |
| Standard | Grade | Chemical Composition Limits (%) | ||||
| C | Si | Mn | P | S | ||
| JIS G3462 | JIS G3461 STB340 | ≤ 0.18 | ≤ 0.3 | 0.30-0.60 | ≤ 0.035 | ≤ 0.035 |
| JIS G3461 STB410 | ≤ 0.32 | ≤ 0.35 | 0.30-0.80 | ≤ 0.035 | ≤ 0.035 | |
| JIS G3461 STB510 | ≤ 0.25 | ≤ 0.35 | 1.00-1.50 | ≤ 0.035 | ≤ 0.035 | |
| Grade | Tensile Property (N/mm2) | Yield Point or Yield Strength (N/mm2) | Elongation (%) | ||
| OD ≥20 mm | 10 mm ≤OD ＜20 mm | OD ＜10 mm | |||
| NO. 11 Sample; NO. 12 Sample | NO. 11 Sample | NO. 11 Sample | |||
| Longitudinal | Transverse | Transverse | |||
| JIS G3462 STB340 | ≥ 340 | ≥ 175 | ≥ 35 | ≥ 30 | ≥ 27 |
| JIS G3462 STB410 | ≥ 410 | ≥ 255 | ≥ 25 | ≥ 20 | ≥ 17 |
| JIS G3462 STB510 | ≥ 510 | ≥ 295 | ≥ 25 | ≥ 20 | ≥ 17 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Jaxon Steel is a leading manufacturer and distributor of high-quality Carbon Steel JIS G3462 Pipe in Houstan, USA. We offer premium steel materials and a comprehensive range of products, including Carbon Steel, Alloy Steel, Mild Steel, and Galvanized Steel. Our extensive inventory features Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets, and Plates. Dedicated to timely delivery and exceptional customer service, we ensure that only the finest raw materials are used, delivering superior performance for all industrial applications with stringent requirements. Contact us today for all your Carbon Steel JIS G3462 Pipe needs.
| Component length (mm) | OD 30-100 mm | OD 100-254 mm |
| 10-100 | + 1.0/- 0 | + 2.0/- 0 |
| 100-600 | + 2.0/- 0 | + 3.0/- 0 |
| 600-1200 | + 3.0/- 0 | + 4.0/- 0 |
| 1200-5000 | + 5.0/- 0 | + 6.0/- 0 |
Carbon Steel JIS G3455 pipes find extensive usage in various industries owing to their greater thermal conductivity, mechanical strength, and durability at extreme conditions. They play a crucial role in the power generation industry in boilers, economizers, and superheaters for efficient heat transfer and enhanced energy output. They are also utilized in fossil fuel plants and steam generation systems due to their strength against high pressure and temperature. JIS G3455 pipes in petrochemical plants and refineries provide long lifespan operation even under corrosive or challenging conditions, providing consistent output and system durability in long operating cycles.
