Luke Steel, based in Houston, Houstan, has earned a solid reputation as a reliable manufacturer and supplier of top-notch Carbon Steel SAW Pipe. They cater to essential industries like oil and gas, petrochemicals, water transmission, and infrastructure development. Known for their pipes’ exceptional weld integrity, strength, and durability, Luke Steel guarantees that every SAW (Submerged Arc Welded) pipe adheres to strict industry and international standards. With state-of-the-art manufacturing facilities, thorough quality control, and dependable supply chains, Luke Steel is well-equipped to support large-scale projects that require robust, leak-proof, and cost-effective piping solutions for high-pressure and long-distance transmission systems.
The Carbon Steel SAW Pipe is crafted from carbon steel plates that contain about 0.20–0.30% carbon, along with balanced amounts of manganese, silicon, and trace elements to boost strength and weldability. These pipes offer a tensile strength ranging from 415–655 MPa and a yield strength typically between 245–485 MPa, showcasing excellent toughness and impact resistance. The submerged arc welding process creates high-quality weld seams with deep penetration, ensuring leak-proof joints and consistent mechanical properties for demanding high-pressure applications.
| Standard | : | API 5L, ASME B36.10M-1996, DIN1626, DIN1629, DIN17175, DIN 2448, JIS G3452, JIS G3454, JIS G3455, JIS G3456, JIS G3457, JIS G3461 |
|---|---|---|
| Sizes (Seamless) | : | 1/2” NB – 60” NB |
| Sizes (ERW) | : | 1/2” NB – 24” NB |
| Sizes (SAW) | : | 16” NB – 100” NB |
| Length | : | Fixed: 5.8, 6.0, 11.8, 12.0m, Random length: 5-12m |
| Schedules | : | Schedule S 5, S 10, S 20, S 40, S 60, S XS, S 80, S 100, S 120, S 140, S 160, S XXS |
| Material | : | Q235, Q345, A53B, A106B, API 5L B, X42, X46, X52, X60, X65, ST37.0, ST35.8, St37.2, St35.4/8, St42, St45, St52, St52.4, STP G38, STP G42, STPT42, STB42, STS42, STPT49, STS49 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| Nominal | Pipe size | OD mm | Schedule 20 | Schedule 30 | Schedule STD | Schedule 40 | Schedule 60 | Schedule Extra | Strong (XS) | |||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Mm | Inch | Wall | Wt. | Wall | Wt. | Wall | Wt. | Wall | Wt. | Wall | Wt. | Wall | Wt. | |
| 3 | 1/8 | 10.3 | 1.73 | 0.37 | 1.73 | 0.357 | 2.41 | 0.47 | ||||||
| 6 | ¼ | 13.7 | 2.24 | 0.63 | 2.24 | 0.625 | 3.02 | 0.804 | ||||||
| 10 | 3/8 | 17.1 | 2.31 | 0.84 | 2.31 | 0.84 | 3.2 | 1.1 | ||||||
| 15 | ½ | 21.3 | 2.77 | 1.26 | 2.77 | 1.26 | 3.73 | 1.62 | ||||||
| 20 | ¾ | 26.7 | 2.87 | 1.69 | 2.87 | 1.68 | 3.91 | 2.2 | ||||||
| 25 | 1 | 33.4 | 3.38 | 2.5 | 3.38 | 2.5 | 4.55 | 3.24 | ||||||
| 32 | 11/4 | 42.2 | 3.56 | 3.39 | 3.56 | 3.38 | 4.85 | 4.47 | ||||||
| 40 | 11/2 | 48.3 | 3.68 | 4.05 | 3.68 | 4.05 | 5.08 | 5.41 | ||||||
| 50 | 2 | 60.3 | 3.9 | 5.44 | 3.9 | 5.44 | 5.5 | 7.48 | ||||||
| 65 | 21/2 | 73 | 5.2 | 8.63 | 5.16 | 8.63 | 7 | 11.41 | ||||||
| 80 | 3/8 | 88.9 | 5.5 | 11.3 | 5.5 | 11.3 | 7.62 | 15.3 | ||||||
| 90 | 31/2 | 1.6 | 5.74 | 13.57 | 5.74 | 13.57 | 8.08 | 18.63 | ||||||
| 100 | 4 | 114.3 | 6.02 | 16.07 | 6.02 | 16.07 | 8.56 | 22.3 | ||||||
| 125 | 5 | 141.3 | 6.6 | 21.77 | 6.55 | 21.77 | 9.53 | 30.9 | ||||||
| 150 | 6 | 168.3 | 7.11 | 28.26 | 7.11 | 28.26 | 10.97 | 42.5 | ||||||
| 200 | 8 | 219.1 | 6.35 | 33.3 | 7 | 36.8 | 8.2 | 42.5 | 8.2 | 42.5 | 10.3 | 53.1 | 12.7 | 64.6 |
| 250 | 10 | 273 | 6.35 | 41.7 | 7.8 | 51.3 | 9.27 | 60.3 | 9.27 | 60.3 | 12.7 | 81.5 | 12.7 | 81.5 |
| 300 | 12 | 323.9 | 6.35 | 49.7 | 8.4 | 65.2 | 9.53 | 73.8 | 10.3 | 79.7 | 14.3 | 109 | 12.7 | 97.4 |
| 350 | 14 | 355.6 | 7.92 | 68.1 | 9.53 | 81.3 | 9.53 | 81.3 | 11.13 | 94.3 | 15.1 | 126.4 | 12.7 | 107 |
| 400 | 16 | 406.4 | 7.92 | 77.9 | 9.5 | 93.3 | 9.53 | 93.3 | 12.7 | 123 | 16.7 | 160 | 12.7 | 123 |
| 450 | 18 | 457.2 | 7.92 | 87.8 | 11.1 | 122 | 9.53 | 105 | 14.3 | 156 | 19 | 206 | 12.7 | 130 |
| 500 | 20 | 508 | 9.53 | 117.2 | 12.7 | 155.1 | 9.53 | 177.2 | 15.1 | 183 | 20.6 | 248 | 12.7 | 155.1 |
| 550 | 22 | 558.8 | 9.53 | 129 | 12.7 | 171 | 9.53 | 129 | 22.2 | 294 | 12.7 | 171 | ||
| 600 | 24 | 609.6 | 9.53 | 141 | 14.3 | 210 | 9.53 | 141 | 17.4 | 255 | 24.5 | 355 | 12.7 | 187 |
Luke Steel is a leading supplier of high-quality Carbon Steel SAW Pipe products in Houstan, USA. We focus on steel solutions and offer a variety of products. This includes Carbon Steel, Alloy Steel, Mild Steel, and Galvanized Steel. Our products are Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets, and Plates. We are known for our good delivery and excellent customer care. We aim to provide strong and durable steel materials for many industrial uses. We work hard to meet high standards, making us a trusted partner for your steel needs.
Carbon Steel SAW Pipe is extensively used for transporting oil, gas, and water over long distances, often found in cross-country pipelines and offshore projects where high-pressure flow is crucial. They also play a vital role in the petrochemical industry, structural piling, and the construction of large water supply systems. SAW pipes are perfect for applications that require large diameters and thick walls, ensuring strength and efficiency in transmission lines. Their outstanding weld integrity, ease of fabrication, and cost-effectiveness make them indispensable in the energy and infrastructure sectors, where durability and reliability are absolutely essential.
Luke Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Houstan, USA.
