Luke Steel stands out as a top-notch manufacturer and supplier of high-strength steel sheets and plates, proudly based in Houston, USA. Renowned for providing premium materials that adhere to strict industry standards, Luke Steel caters to a diverse array of sectors, including construction, automotive, energy, and heavy machinery. The company boasts an impressive range of high-strength steel products designed to deliver exceptional load-bearing capabilities and durability, even in the toughest conditions. With a strong commitment to customer satisfaction, product reliability, and speedy delivery, Luke Steel has earned its reputation as a go-to source for businesses across the United States looking for trustworthy high-strength steel sheet and plate solutions.
High-strength steel sheets and plates are crafted for outstanding mechanical performance and toughness. They often include alloying elements like carbon, manganese, chromium, and occasionally vanadium or nickel, which enhance their strength-to-weight ratios and wear resistance. These materials showcase impressive tensile strengths, ranging from 600 MPa to over 1300 MPa, along with excellent yield strength, formability, and weldability, depending on the specific grade. Despite their robust strength, they strike a balance between ductility and toughness, making them perfect for demanding structural applications. Their lightweight design also boosts efficiency in load-bearing structures without sacrificing safety.
| Item | High Strength Steel Plate |
| Material | 450 Yield ,A36 ,A516 ,A572 , A573 ,A588 , A606 ,A709 Grade 50 ,A871 Grade 65 ,AASHTO M270 ,CSA G40.21 ,Hot Rolled Steel Plate,PVQ A283 ,PVQ A285 ,SAILMA Grade 350 HI , SAILMA Grade 450 HI |
| Thickness | 6-300mm |
| Width | 900-4100mm |
| Length | 3000-25000mm |
| Type | Steel Plate |
| S | Cr | P | Al | C | Ni | Si | Mo | Mn |
|---|---|---|---|---|---|---|---|---|
| 0.005 max | 1.50 max | 0.0.20 max | 0.015 max | 0.20 max | 2.0 max | 0.80 max | 0.70 max | 1.70 max |
| Thickness milimeter | Rm MPa | Re MPa | A % |
|---|---|---|---|
| < 50 | 770 – 940 | 690 | 14 |
| > 50 ? 100 | 760 – 930 | 650 | 14 |
| > 100 | 710 – 900 | 630 | 14 |
| grade | DENSITY | (MPA)YIELD STRENGTH |
|---|---|---|
| water quenched 480 °C (900 °F), temper 855 °C (1570 °F) AISI 4130 | 7.85 G/CM³ | 951 |
| clear cast sheet (PMMA), Acrylic | 1.16 G/CM³ | 72 |
| Steel, high strength alloy ASTM A514 | 7.8 G/CM³ | 690 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
|
Grade
|
Nominal Thickness t (mm)
|
||
|
3 ≤ t ≤ 50
|
50 < t ≤ 100
|
100 < t ≤ 150
|
|
|
Minimum yield strength ReH, MPa
|
|||
|
S460Q
|
460
|
440
|
400
|
|
S500Q
|
500
|
480
|
440
|
|
S550Q
|
550
|
530
|
490
|
|
S620Q
|
620
|
580
|
560
|
|
S690Q
|
690
|
650
|
630
|
|
S890Q
|
890
|
830
|
|
|
S960Q
|
960
|
|
|
|
|
Tensile strength Rm, MPa
|
||
|
S460Q
|
550-720
|
500-670
|
|
|
S500Q
|
590-770
|
540-720
|
|
|
S550Q
|
640-820
|
590-770
|
|
|
S620Q
|
700-890
|
650-830
|
|
|
S690Q
|
770-940
|
760-930
|
710-900
|
|
S890Q
|
940-1100
|
880-1100
|
|
|
S960Q
|
980-1150
|
|
|
|
Quality
|
Test Temperature °C
|
|||
|
-20
|
-40
|
-50
|
-60
|
|
|
M
|
40J
|
|
|
|
|
ML
|
|
|
27J
|
|
|
Q
|
30J
|
|
|
|
|
QL
|
|
30J
|
|
|
|
QL1
|
|
|
|
30J
|
High-strength steel sheets and plates find extensive use in industries that demand materials with exceptional load resistance and structural integrity. In construction, they play a crucial role in building bridges, structures, and load-bearing frameworks. The automotive sector relies on them to create lighter, safer, and more fuel-efficient vehicles. In heavy equipment and mining, these materials enhance wear resistance and prolong service life. They are also utilized in shipbuilding, pressure vessels, wind towers, and various industrial fabrication projects. Their impressive strength-to-weight efficiency and durability make them ideal for applications where performance and safety are paramount.
Luke Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Houstan, USA.
