Luke Steel is a reliable supplier and producer of NICRODUR 400 Plates and Sheets in the United Arab Emirates and USA, providing durable steel solutions for heavy-duty and abrasive conditions. With its superior wear resistance and exceptional durability, NICRODUR 400 is designed to satisfy industry-specific requirements and global standards. With a deep commitment to customer satisfaction, quality, and accuracy, Luke Steel produces dependable products with technical support and a smooth supply chain. NICRODUR 400 Sheets and Plates are perfect for utilitarian industries like mining, construction, and material handling, where long lifespan and low maintenance are essential.
NICRODUR 400 Sheets and Plates are alloy steel materials that are engineered to achieve optimal hardness and abrasion resistance. Their alloy structure usually consists of carbon, manganese, chromium, and other strengthening alloying elements. Heat treated by quenching and tempering, these plates attain a nominal hardness of around 400 HBW. They provide a balanced combination of high tensile strength, good impact resistance, and good weldability. Designed for mechanical tolerance and long-term application, NICRODUR 400 delivers reliable performance in erosive conditions and is thus best suited for high-strength, abrasion-resistant materials in severe operating conditions demanded by a particular industry.
Item: NICRODUR 400
Thickness : 5mm to 150mm
Length : 6,000mm to 12,000mm
Width : 1,500mm to 2,500mm
Heat Treatment: N, Q+T
Surface Point : EP, PE, HDP, SMP, PVDF
| PLATE | C | Si | Mn | P | S | Cr | Ni | Mo | B | CEV | CET |
| THICKNESS MM | MAX % | MAX % | MAX % | MAX % | MAX % | MAX % | MAX % | MAX % | MAX % | TYPV | TYPV |
| 4-13 | 0.27 | 0.7 | 1.6 | 0.025 | 0.01 | 1.0 | 0.25 | 0.25 | 0.004 | 0.49 | 0.34 |
| (13) -32 | 0.29 | 0.7 | 1.6 | 0.025 | 0.01 | 1.0 | 0.50 | 0.30 | 0.004 | 0.62 | 0.41 |
| (32) -40 | 0.29 | 0.7 | 1.6 | 0.025 | 0.01 | 1.0 | 1.00 | 0.60 | 0.004 | 0.64 | 0.43 |
| (40) -80 | 0.30 | 0.7 | 1.6 | 0.025 | 0.01 | 1.50 | 1.50 | 0.60 | 0.004 | 0.74 | 0.46 |
| Thickness | Hardness HBW | Typical yield strength MPa, |
| mm | min – max 1 | not guaranteed |
| 4 – 32 | 470 – 530 | 1250 |
| (32) – 103 | 450 – 540 | 1250 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| 1/8″ | 3/8″ | 3/4″ | 1-1/2″ | 3″ |
| 3/16″ | 1/2″ | 1″ | 2″ | 4″ |
| 1/4″ | 5/8″ | 1-1/4″ | 2-1/2″ | |
| *1/8″ thick plate is available in one size only 60″x 120″. The 3/6″ thick plate is available only as 48″ x 144″ and 96″ x 144″. | ||||
| Thickness | Width | Length |
| 4 | 2000 | 6000 |
| 5 | 2000 | 6000 |
| 6 | 2000 | 6000 |
| 6 | 2500 | 6000 |
| 8 | 2000 | 6000 |
| 8 | 2500 | 6000 |
| 10 | 2000 | 6000 |
| 12 | 2000 | 6000 |
| 15 | 2000 | 6000 |
| 16 | 2000 | 6000 |
| 20 | 2000 | 6000 |
| 25 | 2000 | 6000 |
| 32 | 2000 | 6000 |
| 40 | 2000 | 6000 |
| 50 | 2000 | 6000 |
| 60 | 1800 | 3400 |
