Luke Steel is your reliable manufacturer and supplier of high-quality NICRODUR 450 Sheets and Plates, proudly located in the USA. Leaders in providing wear-resistant steel solutions that meet and surpass global standards, Luke Steel is committed to quality, innovation, and customer satisfaction. Supported by state-of-the-art manufacturing processes and responsive supply chain, the company offers products designed for durability, toughness, and long-term performance. Whether supplying local industries or international markets, Luke Steel provides on-time delivery, competitive pricing, and superb service. Their NICRODUR 450 plates are suitable for heavy-duty applications in the construction, mining, heavy machinery, and material handling industries.
NICRODUR 450 Sheets and Plates are produced from wear-resistant alloyed steel that includes carbon, manganese, chromium, and molybdenum. The alloying components increase the plates’ hardness, abrasion resistance, and strength. With a nominal surface hardness of around 450 HBW, the material provides outstanding tensile strength (1400–1600 MPa) and high yield strength of around 1200 MPa. NICRODUR 450 provides excellent impact resistance, good formability under favorable conditions, and preserves its toughness at low temperatures. It is thus a perfect option for heavy-duty, high-impact usage in demanding operating conditions.
Item: NICRODUR 450
Thickness : 5mm to 150mm
Length : 6,000mm to 12,000mm
Width : 1,500mm to 2,500mm
Heat Treatment: N, Q+T
Surface Point : EP, PE, HDP, SMP, PVDF
| Plate Thickness [mm] | C max | Si max | Mn max | S max | P max | Cr max | Ni max | Mo max | B max | CEV max | |
| 8 – 20 | 0,18 | 1,0 | 1,5 | 0,002 | 0,012 | 0,8 | 0,5 | 0,5 | 0,004 | 0,47 | |
| (20) – 40 | 0,19 | 1,0 | 1,5 | 0,002 | 0,012 | 0,9 | 0,5 | 0,5 | 0,004 | 0,56 | |
| (40) – 60 | 0,23 | 1,0 | 1,5 | 0,002 | 0,012 | 1,1 | 0,5 | 0,5 | 0,004 | 0,65 | |
| (60) – 80 | 0,25 | 1,0 | 1,5 | 0,002 | 0,012 | 1,1 | 0,5 | 0,5 | 0,004 | 0,71 |
| Yield strength(minimal), Re [MPa] | Tensile strength, Rm [MPa] | Elongation (minimal), A5 [%] | |
| NICRODUR 450 | 1280 | 1450 | 9 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| 1/8″ | 3/8″ | 3/4″ | 1-1/2″ | 3″ |
| 3/16″ | 1/2″ | 1″ | 2″ | 4″ |
| 1/4″ | 5/8″ | 1-1/4″ | 2-1/2″ | |
| *1/8″ thick plate is available in one size only 60″x 120″. The 3/6″ thick plate is available only as 48″ x 144″ and 96″ x 144″. | ||||
| Thickness | Width | Length |
| 4 | 2000 | 6000 |
| 5 | 2000 | 6000 |
| 6 | 2000 | 6000 |
| 6 | 2500 | 6000 |
| 8 | 2000 | 6000 |
| 8 | 2500 | 6000 |
| 10 | 2000 | 6000 |
| 12 | 2000 | 6000 |
| 15 | 2000 | 6000 |
| 16 | 2000 | 6000 |
| 20 | 2000 | 6000 |
| 25 | 2000 | 6000 |
| 32 | 2000 | 6000 |
| 40 | 2000 | 6000 |
| 50 | 2000 | 6000 |
| 60 | 1800 | 3400 |
Luke Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Houstan, USA.
