Luke Steel is a reliable US-based manufacturer and supplier of top-quality NICRODUR 500 Sheets and Plates. Known for quality and accuracy, we provide high-performance, wear-resistant steel solutions that support the most demanding industrial applications. Our NICRODUR 500 solutions are designed for the highest strength and durability, sourced and processed with strict attention to detail. Backed by a professional team and an effective supply chain, Luke Steel delivers on-time and total customer satisfaction. Across mining and construction, and heavy equipment manufacturing, we are the business partner of choice for companies that need top–notch steel with quality predictability and performance.
NICRODUR 500 Sheets and Plates consist of high-strength quenched and tempered alloy steel having a chemical composition comprising carbon, manganese, chromium, nickel, and boron. These constituents deliver improved hardness, strength, and abrasion resistance. NICRODUR 500 has a nominal hardness of 500 HBW, yield strength of approximately 1200 MPa, and tensile strength up to 1600 MPa. This ensures high wear resistance, toughness, and structural integrity even under harsh mechanical stress. The plates retain high performance in adverse environments, rendering them suitable for heavy-duty applications in industry.
Item: NICRODUR 500
Thickness : 5mm to 150mm
Length : 6,000mm to 12,000mm
Width : 1,500mm to 2,500mm
Heat Treatment: N, Q+T
Surface Point : EP, PE, HDP, SMP, PVDF
| Plate Thickness [mm] | C max | Si max | Mn max | S max | P max | Cr max | Ni max | Mo max | B max | CEV max | |
| 8 – 25 | 0,28 | 1,0 | 1,5 | 0,002 | 0,012 | 1,0 | 0,5 | 0,5 | 0,005 | 0,61 | |
| (20) – 40 | 0,32 | 1,0 | 1,5 | 0,002 | 0,012 | 1,1 | 0,5 | 0,5 | 0,005 | 0,71 | |
| (40) – 60 | 0,34 | 1,0 | 1,5 | 0,002 | 0,012 | 1,2 | 0,7 | 0,5 | 0,005 | 0,76 | |
| (60) – 80 | 0,40 | 1,0 | 1,5 | 0,002 | 0,012 | 1,5 | 1,0 | 0,5 | 0,005 | 0,81 |
| Yield strength(minimal), Re [MPa] | Tensile strength, Rm [MPa] | Elongation (minimal), A5 [%] | |
| NICRODUR 500 | 1500 | 1800 | 9 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| 1/8″ | 3/8″ | 3/4″ | 1-1/2″ | 3″ |
| 3/16″ | 1/2″ | 1″ | 2″ | 4″ |
| 1/4″ | 5/8″ | 1-1/4″ | 2-1/2″ | |
| *1/8″ thick plate is available in one size only 60″x 120″. The 3/6″ thick plate is available only as 48″ x 144″ and 96″ x 144″. | ||||
| Thickness | Width | Length |
| 4 | 2000 | 6000 |
| 5 | 2000 | 6000 |
| 6 | 2000 | 6000 |
| 6 | 2500 | 6000 |
| 8 | 2000 | 6000 |
| 8 | 2500 | 6000 |
| 10 | 2000 | 6000 |
| 12 | 2000 | 6000 |
| 15 | 2000 | 6000 |
| 16 | 2000 | 6000 |
| 20 | 2000 | 6000 |
| 25 | 2000 | 6000 |
| 32 | 2000 | 6000 |
| 40 | 2000 | 6000 |
| 50 | 2000 | 6000 |
| 60 | 1800 | 3400 |
