Luke Steel is a reliable manufacturer and supplier of high-quality S315MC Sheets and Plates, serving proudly in the USA and United Arab Emirates. We are known for providing sturdy steel solutions for severe structural and engineering applications and follow the EN 10149-2 standard for thermomechanically rolled steels. Our S315MC plates are high in yield strength, cold formability, and accuracy in dimensions, making them the industry leader in industries like automotive, construction, and fabrication. With technical accuracy as a mission, speedy delivery, and compliance with global quality standards, Luke Steel ensures customer satisfaction and reliable product performance in high-demanding environments.
S315MC Sheets and Plates are micro-alloyed, hot-rolled steels, containing ≤0.12% Carbon, ≤1.60% Manganese, Phosphorus, Sulphur, and micro-alloying components such as niobium, titanium, and vanadium. These components refine the grain structure and add strength. The steel offers a minimum yield strength of 315 MPa and tensile strength of 390–510 MPa. Its low carbon equivalent has good weldability and superior cold-forming qualities. The synergy of mechanical properties and processability renders S315MC suitable for application in weight-critical and high-load structural parts, promoting precision, durability, and long-term reliability.
| Steel grade type | Carbon steel: |
|---|---|
| Standard | |
| Production specifications | Steel plate,Sheet, Coil,Flat bar,Round bar, Strip steel,wire,All kinds of forgings. |
| Mchining | Turning Milling Grinding Deep hole drilling: length max 9.8 meters. |
| Range of work | Round bar steel: 1mm to 2000mm Square-shape steel: 10mm to 1000mm steel Plate/sheet:0.08mm to 800mm Width: 10mm to 1500mm Lenth: We can supply any lenth based on the customer’s requirement. Forging: Shafts with flanks/pipes/tubes/slugs/donuts/cubes/other shapes Tubings: OD: φ4-410 mm, with wall thickness ranging from 1-35 mm. |
| Heat treatment | Normalizing,Annealing,Tempering,Quenching,Hardening and tempering,Seasoning,Surface hardening,Carburizing |
| Grade | C | Si | Mn | P | S | Altotal | Mo | Ti | B |
| EN 10149-2 S315MC | 0,12 max | 0,50 max | 1,30 max | 0,025max | 0,020 | 0,015 | – | 0,15 | – |
| Grade | Mechanical properties | Yield Strength ReH [N/mm2] t ransv.min. | Tensile Strength Rm [N/mm2] transv. | Min.totalel ongation [%] | Smallest recom mended bending radius bending angles ≤ 90 | |||
| EN 10149-2 S315MC | S315MC | 315 | 390 – 510 | L0 = 80 mm | L0= 5,65 √S0 | e1) ≤ 3 | 3 < e1)< 6 | e1) > 6 |
| e2) < 3 | e2) ≥ 3 | |||||||
| 20 | 24 | 0,25 e | 0,5 e | 1,0 e | ||||
| Grade | S315MC EN 10149-2 Material #: 1.0972 | Comparison of steel grades | |
| EN 10149-2 S315MC | NFA 36-231 | E 315 D | |
| BS 1449 | HR 43F35 | ||
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| Quantity | Value | Unit |
|---|---|---|
| Thermal expansion | 16 – 17 | e-6/K |
| Thermal conductivity | 16 – 16 | W/m.K |
| Specific heat | 500 – 500 | J/kg.K |
| Melting temperature | 1370 – 1400 | °C |
| Service temperature | 0 – 500 | °C |
| Density | 8000 – 8000 | kg/m3 |
| Resistivity | 0.7 – 0.7 | Ohm.mm2/m |
S315MC Sheets and Plates are used extensively by industries that require a balance of formability, strength, and weldability. In the automotive industry, they are extensively employed in chassis components, frames, beams, and reinforcements to enable lightweight, high-strength designs. They are used in construction for load-bearing structures, bridges, and constructed frameworks. They are also suitable for machinery, trailers, containers, and farm equipment where strength-to-weight efficiency is essential. With stable mechanical properties and good workability, S315MC plates can be applied to both precision-formed parts and structural steel assemblies in a range of engineering fields.
