Luke Steel is a renowned producer and supplier of high-grade S650MC Plates and Sheets, serving the USA and the United Arab Emirates with pride. Renowned for providing high-strength steel solutions that are specifically suited for demanding structural and engineering applications, our S650MC range adheres to strict EN 10149-2 standards and is renowned for its superior formability, weldability, and strength-to-weight ratio. At Luke Steel, we cater to various industries such as construction, automotive, and heavy machinery with a strong emphasis on quality, prompt delivery, and technical assistance. Our competitive prices and adherence to excellence have made us a reliable supplier across the USA and the wider GCC region.
S650MC Sheets and Plates are thermomechanical rolled, low-alloy steels primarily made up of carbon, manganese, and micro-alloying elements like niobium, titanium, and vanadium. All these aspects improve grain refinement and mechanical properties. The steel has a minimum yield strength of 650 MPa and tensile strength of 700–900 MPa, with remarkable cold-forming ability, impact resistance, and elongation. With low carbon content, weldability is superior, and the fine-grained structure improves toughness and fatigue strength. S650MC is the best option for structural elements where high strength, low weight, and uniform performance under dynamic loading is needed.
| Material | Strenx 650 |
| Standards | EN 10149-2, EN 10051, EN 10163-2 |
| Thickness | 2.00 to 10.00 milimeter |
| Width | up to 1600 milimeter |
| Length | Up to 16000 milimeter |
| C | Mo | S | B | Mn | Si | Alt | P | Nb | V | Ti |
| ≤0.12 | ≤0.50 | ≤0.015 | ≤0.005 | ≤2.00 | ≤0.60 | ≤0.015 | ≤0.025 | ≤0.09 | ≤0.20 | ≤0.22 |
Elongation | tensile strength | 180°bend | Yield Strength(MPa) |
10 | 700-880 | d=2a | 650 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| Thickness (mm) | Weight Theoretical | Weight Theoretical | ||
| Kg/m2 | Kg/ft2 | Kg/ft2 | Kg/m2 | |
| 0.90 | 7.065 | 0.656 | 4.376 | 47.100 |
| 0.80 | 6.280 | 0.583 | 4.011 | 43.175 |
| 0.75 | 5.888 | 0.547 | 3.646 | 39.250 |
| 1.0 | 7.850 | 0.729 | 4.740 | 51.025 |
| 1.9 | 14.915 | 1.386 | 10.916 | 117.500 |
| 1.2 | 9.420 | 0.875 | 5.470 | 58.875 |
| 1.6 | 12.560 | 1.167 | 8.387 | 90.275 |
| 1.4 | 10990 | 1.021 | 6.928 | 74.575 |
| 2.2 | 17.270 | 1.604 | 12.398 | 133.450 |
| 1.3 | 10.205 | 0.948 | 5.834 | 62.800 |
| 1.7 | 13.345 | 1.240 | 8.751 | 94.200 |
| 1.5 | 11.775 | 1.094 | 7.293 | 78.500 |
| 1.1 | 8.635 | 0.802 | 5.105 | 54.950 |
| 2.3 | 18.055 | 1.677 | 13.127 | 141.300 |
| 1.8 | 14.130 | 1.313 | 10.210 | 100.900 |
| 3.5 | 27.475 | 2.553 | 15.315 | 164.850 |
| 2.0 | 15.700 | 1.459 | 11.669 | 125.600 |
| 2.5 | 19.625 | 1.823 | 13.856 | 149.150 |
| 3.0 | 23.550 | 2.188 | 14.586 | 157.000 |
| 4.0 | 31.400 | 2.917 | 16.044 | 172.700 |
S650MC Sheets and Plates are extensively applied in high-strength, weight-critical applications requiring structural integrity and fatigue resistance. They are utilized in chassis, suspension systems, and safety reinforcements in the automotive sector, supporting lightweight design and increased vehicle efficiency. In infrastructure and construction, S650MC is utilized in bridges, support beams, and heavy-load structures. It‘s also perfect for cranes, trailers, and lifting equipment, providing strength without sacrificing maneuverability. Its superior formability and weldability make it ideal for making complex precision-formed parts that will endure dynamic forces, which will provide long-term service in demanding engineering conditions.
