Luke Steel is your trusted manufacturer and provider of SA 516 GR.70N NACE HIC Plates, serving customers from our hub in Houston, USA with pride. We are specialized in pressure vessel-grade steel plates and strictly follow NACE MR0175 specifications to provide HIC-resistant materials. With a significant footprint in the Middle East and Gulf region, Luke Steel services mission–critical industries like oil, gas, and petrochemicals. Our dedication to product quality, timely delivery, and outstanding customer service ensures our clients prefer us to meet their corrosion-resistant, high-performance steel solutions for challenging environments and applications.
SA 516 GR.70N NACE HIC Plates are manufactured from high-quality carbon steel and contain major elements such as carbon, manganese, phosphorus, sulfur, and silicon. The plates are normalized and further treated with HIC-resistant material to make them appropriate for sour service conditions. These plates have strict NACE MR0175 requirements, providing a minimum yield strength of 260 MPa and tensile strength of 485–620 MPa. Their superior notch toughness and well-documented resistance to hydrogen sulfide (H₂S) environments provide high margins of safety in harsh pressure vessel applications even in aggressive operating conditions common in the oil and gas sector.
| Grade | ASME SA 516 GR.65N Boiler and Pressure Vessel Steel Plates |
|---|---|
| Width | 1000mm-4500mm |
| Thickness | 5mm-150mm |
| Length | 3000mm-18000mm |
| Supply Condition | As Rolled, Normalized Rolling, Furnace Normalizing, Vacuum Degassing, Simulated Post-Weld Heat Treatment or as per customer requirement. |
| Impact tested | 52° C |
| Tempering | Notch toughness can be improved by quenched cooling from hot rolling or normalizing by the supplier. If such a faster cooling rate is agreed upon between purchaser and supplier then the steel is also to be tempered at 1200 F. |
| Applications | Used for weld fabrication of pressure vessels that require improved notch toughness for lower than ambient temperature service. |
| Process of Manufacturing | Hot-Rolled (HR) |
| C | Si | Mn | P | S | Al | Cr | Cu | Ni | Mo | Nb | Ti | V |
| 0.08/0.20 | 0.4 | 0.9/1.5 | 0.03 | 0.03 | 0.02 | 0.3 | 0.3 | 0.3 | 0.08 | 0.01 | 0.03 | 0.02 |
| Tensile strength (ksi) | Tensile strength (MPa) | Yield strength (ksi) | Yield strength (MPa) | Elongation in 200mm (min)(%) | Elongation in 50mm (min) (%) |
| 65-85 | 450-585 | 35 | 240 | 19 | 23 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| British Standard | European Norm | ASTM/ASME | DIN |
| BS1501-224-460A/B | EN10028 P295GH | A/SA516 – Grade 65 | DIN 17155 17 MN 4 |
Jaxon Steel is a trusted manufacturer and supplier of high-quality SA 516 GR.65N NACE and MR 0103-0175 Plates in Houstan, USA. We specialize in premium steel products, including Alloy Steel, Carbon Steel, Mild Steel and Galvanized Steel, with a strong focus on Carbon Steel Sheet and Plates. Our extensive inventory also includes Pipes, Tubes, Flanges, Forged Fittings and Bars. Committed to fast delivery and exceptional customer service, we use only the finest raw materials to ensure superior strength, durability and performance for critical industrial applications. Contact us today for all your SA 516 GR.65N NACE and MR 0103-0175 Plates needs!
You will discover SA 516 GR.70N NACE HIC Plates used extensively in industries requiring high resistance to hydrogen-induced cracking and good pressure retention. They are prevalent in pressure vessels, heat exchangers, storage tanks, and boiler components in oil refineries, petrochemical plants, gas processing units, and power generation industries. Their very good mechanical strength and corrosion resistance make them ideal for tough environments, particularly in sour service operations. These plates provide lasting performance and increased safety, reducing the chance of failures and downtime. Luke Steel is devoted to prompt delivery and has the flexibility to accommodate special requirements of projects around Houston and the surrounding Gulf area.
Luke Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Houstan, USA.
