Based in the United States and the United Arab Emirates, Luke Steel is a top producer and supplier of SA 516 Grade 70 Sheets and Plates. It is renowned for providing premium boiler and pressure vessel steel that satisfies important industrial requirements. Our SA 516 Gr 70 plates, which are widely used in industries like oil and gas, petrochemicals, and power generation, are designed to endure harsh service conditions. Providing certified, ASTM-compliant materials that are supported by stringent testing and quality assurance is our top priority. Luke Steel stands out as a trustworthy steel partner throughout the United Arab Emirates and the Middle East thanks to its reputation for on-time delivery, technical accuracy, and customer satisfaction.
SA 516 Grade 70 is a carbon steel plate alloyed with carbon (0.27–0.31%), manganese (0.79–1.30%), and small amounts of phosphorus and sulfur (max 0.035%). It offers a minimum yield strength of 260 MPa and exceptional tensile strength between 485 and 620 MPa. It exhibits improved ductility, impact resistance, and notch toughness when supplied in the normalized state, particularly at low temperatures. It is perfect for intricate fabrication because of its exceptional weldability. Because of these characteristics, SA 516 Gr 70 is ideal for equipment that contains pressure and operates under thermal stresses and fluctuating pressures.
Grade :Â ASME SA 516 GR.65 Boiler and Pressure Vessel Steel Plates
Width :Â 1250mm-3000mm
Thickness : 3 – 200 mm/ dimensions up to 4.000 mm
Length :Â 3000mm-11000mm.
Production :Â Hot-Rolled (HR)
Heat Treatment :Â Rolled/Normalised/N+T/QT
| C | Si | Mn | P | S | Al | Cr | Cu | Ni | Mo | Nb | Ti | V |
| 0.08/0.20 | 0.4 | 0.9/1.5 | 0.03 | 0.03 | 0.02 | 0.3 | 0.3 | 0.3 | 0.08 | 0.01 | 0.03 | 0.02 |
| Tensile strength (ksi) | Tensile strength (MPa) | Yield strength (ksi) | Yield strength (MPa) | Elongation in 200mm (min)(%) | Elongation in 50mm (min) (%) |
| 65-85 | 450-585 | 35 | 240 | 19 | 23 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
SA 516, Grade 70 Boilers, storage tanks, pressure vessels, and heat exchangers are all frequently constructed using sheets and plates. In sectors where high-pressure containment and thermal stability are critical, such as chemical processing, oil refining, thermal power plants, and gas handling facilities, they are indispensable. In dynamic and high-stress situations, the material’s high tensile strength, notch toughness, and weldability guarantee structural integrity. It is a favored option for crucial mechanical systems and industrial structures due to its capacity to function dependably under a range of temperatures and pressures, providing long-term durability, safety, and performance efficiency.
