Based in Houston, Texas, Luke Steel is a well-known producer and supplier of high-quality SAE 1045 steel plates and sheets. The business, which is renowned for producing superior steel, focuses on offering precisely engineered materials that are suited to the needs of the manufacturing, engineering, and construction sectors. SAE 1045 is perfect for demanding applications because of its strength, durability, and machinability. Luke Steel is dedicated to maintaining industry standards by providing exceptional customer service, technical know-how, and consistent quality. We provide steel solutions that guarantee performance and dependability in a variety of industries, whether they are for high-wear industrial components or structural parts.
SAE 1045 steel is a medium-carbon steel that normally contains trace amounts of phosphorus and sulfur in addition to 0.43–0.50% carbon and 0.60–0.90% manganese. With a Brinell hardness of 170–210 HB, a tensile strength of 570–700 MPa, and a yield strength of about 300 MPa, it provides exceptional mechanical qualities. The material is valued for its high surface hardness following heat treatment, good machinability, and respectable weldability. Due to these qualities, SAE 1045 is perfect for manufacturing parts that need to be strong, durable, and resistant to wear, particularly in mechanical settings that are subjected to high stress.
| Specification | ASTM A830 AISI 1045, SAE 1045, |
| Grade | SAE J403 Grade 1045 |
| Condition | hot rolled or normalized |
| Width | Â 200 to 2000mm |
| Thickness | Â 6 to 800mm |
| Length | 2000 to 6000mm |
| Heat treated method | By flame or induction |
| MN | FE | S | C | P |
|---|---|---|---|---|
| 0.60 – 0.90% | 98.51 – 98.98% | ≤ 0.050% | 0.420 – 0.50% | ≤ 0.040% |
| MECHANICAL PROPERTIES | Â | Â |
|---|---|---|
| Â | Metric | Imperial |
| Tensile Strength, Ultimate | 565 MPa | 81,900 PSI |
| Tensile Strength, Yield | 310 MPa | 45,000 PSI |
| Modulus of Elasticity | 200 GPa | 29,000 KSI |
| Hardness, Brinell | 163 | 163 |
| Elongation at Break (in 50 mm) | 16.0% | 16.0% |
| Bulk Modulus (Typical for Steel) | 140 GPa | 20,300 KSI |
| Poissons Ratio | 0.290 | 0.290 |
| Shear Modulus | 80 GPa | 11,600 KSI |
| Grade | EU EN | DIN,WNr | JIS | AFNOR | BS | GOST | ISO | UNS |
| 1045 | C45E (1.1191) | Ck45 | S45C | XC45 XC48H1 | 080M46 CFS8 | 45 | C45E4 | G10450 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| Length x Width | Thickness |
|---|---|
| mm | mm |
| 2000 x 1000 | 0.8 |
| 2440 x 1220 | 1.0 |
| 2500 x 1250 | 0.9 |
| 2500 x 1250 | 0.8 |
| 2000 x 1000 | 1.20 |
| 2000 x 1000 | 1.0 |
| 2000 x 1000 | 0.9 |
| 1830 x 1220 | 1.0 |
| 2500 x 1250 | 1.20 |
| Thickness | Length x Width | Mass per Sq m |
|---|---|---|
| mm | mm | Kg/m2 |
| 30.00 | 2000 x 1000 | 235.50 |
| 30.00 | 4000 x 2000 | 235.50 |
| 30.00 | 2500 x 1250 | 235.50 |
| 30.00 | 5000 x 2500 | 235.50 |
| 30.00 | 3000 x 1500 | 235.50 |
| 30.00 | 5000 x 1250 | 235.50 |
| 40.00 | 2000 x 1000 | 314.00 |
| 32.00 | 2000 x 1000 | 251.20 |
| 30.00 | 10000 x 2500 | 235.50 |
| 30.00 | 6000 x 2500 | 235.50 |
| 32.00 | 2500 x 1250 | 251.20 |
| 32.00 | 3000 x 1500 | 251.20 |
| 32.00 | 5000 x 2500 | 251.20 |
| 32.00 | 4000 x 2000 | 251.20 |
| 35.00 | 3000 x 1500 | 274.75 |
| 35.00 | 4000 x 2000 | 274.75 |
| 35.00 | 2500 x 1250 | 274.75 |
| 40.00 | 2500 x 1250 | 314.00 |
| 40.00 | 3000 x 1500 | 314.00 |
| 40.00 | 4000 x 2000 | 314.00 |
Industries that require strength, impact resistance, and wear durability frequently use SAE 1045 steel plates and sheets. Gears, axles, crankshafts, bolts, shafts, and forged parts are among the common uses. Because of its machinability and capacity to support dynamic loads, it is also widely used in hydraulic clamps, farm equipment, construction machinery, and industrial equipment. Its ability to produce mechanical parts and structural supports is valued by the engineering and automotive industries. SAE 1045 provides a flexible solution for heavy-duty applications needing toughness and dimensional stability because it can be heat-treated for additional hardness and strength.
